MACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SS
MACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SS
MACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SS
MACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SS
MACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SS
MACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SS
MACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SS
MACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SS
Specifications
Brand Name :
SFT
Model Number :
MR12-2-2RS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000PCS/MONTH
Delivery Time :
20-45DAYS
Packaging Details :
carton,pallet
Lubrication :
Grease Lubrication
Bore Size :
1 - 19.05 mm
Number of Row :
Single Row
Feature :
High Speed Low Noise
Precision Rating :
P0,P4,P6
Cage material :
nylon & metal
Description

MACHINED TYPE NEEDLE ROLLER BEARINGS MR-12 MR12.2R

Product Description

The needle roller bearing is a bearing which uses small cylindrical rollers.They are used to reduce friction of a rotating surface. Needle bearings have a large surface area that is in contact with the bearing outer surfaces compared to ball bearings. Additionally there is less added clearance (difference between the diameter of the shaft and the diameter of the bearing) so they are much more compact.

The typical structure consists of a needle cage which orients and contains the needle rollers,the needle rollers thems.elves, and an outer race (sometimes the housing itself).Radial needle bearings are cylindrical and use rollers parallel to the axis of the shaft.Thrust needle bearings are flat and use a radial pattern of needles.Full complement bearings have solid inner and outer rings and rib-guided cylindrical rollers.

Application

Needle roller bearings are widely used in cars, compressors, construction,electric motors,

food industry, home appliances etc. As a rolling element, it turns the world.

Feature

1.Cam follower with needle rollers supports high static and dynamic loads in cam- and track-type applications
2.Stud-type design with a screwdriver slot for through-hole or threaded mounting
Full complement of rollers for higher radial load capacity than caged rollers
3.Nylon lip seals help retain lubricant and prevent contamination
4.Black oxide- treated bearing steel for durability and corrosion resistance

Needle roller bearings size:

Part No.
Dimensions (Inch)
Approx.
Appropriate Inner Race
F
D
B
Wgt. lbs
MR-10-2RS
0.625
1.125
1
0.156
MI-6
MR-12-2RS
0.75
1.25
1
0.171
MI-8
MR-14-2RS
0.875
1.375
1
0.187
MI-10
MR-16-2RS
1
1.5
1
0.218
MI-12
MR-16-2RS
1
1.5
1
0.218
MI-13
MR-18-2RS
1.125
1.625
1.25
0.282
MI-14
MR-18-2RS
1.125
1.625
1.25
0.282
MI-15
MR-20-2RS
1.25
1.75
1.25
0.38
MI-16
MR-22-2RS
1.375
1.875
1.25
0.41
MI-17
MR-22-2RS
1.375
1.875
1.25
0.41
MI-18
MR-24-2RS
1.5
2.0625
1.25
0.438
MI-19
MR-24-2RS
1.5
2.0625
1.25
0.438
MI-20
MR-26-2RS
1.625
2.1875
1.25
0.468
MI-21
MR-26-2RS
1.625
2.1875
1.25
0.468
MI-22-4S
MR-28-2RS
1.75
2.3125
1.25
0.5
MI-22
MR-28-2RS
1.75
2.3125
1.25
0.5
MI-23
MR-28-2RS
1.75
2.3125
1.25
0.5
MI-24
MR-30-2RS
1.875
2.4375
1.25
0.527
MI-25-4S
MR-32-2RS
2
2.5625
1.25
0.562
MI-25
MR-32-2RS
2
2.5625
1.25
0.562
MI-26
MR-32-2RS
2
2.5625
1.25
0.562
MI-27
MR-36-2RS
2.25
3
1.75
1.25
MI-28
MR-36-2RS
2.25
3
1.75
1.25
MI-30
MR-40-2RS
2.5
3.25
1.75
1.38
MI-31
MR-40-2RS
2.5
3.25
1.75
1.38
MI-32
MR-40-2RS
2.5
3.25
1.75
1.38
MI-34
MR-44-2RS
2.75
3.5
1.75
1.6
MI-35
MR-44-2RS
2.75
3.5
1.75
1.6
MI-36
MR-48-2RS
3
3.75
1.75
1.75
MI-38
MR-48-2RS
3
3.75
1.75
1.75
MI-39
MR-48-2RS
3
3.75
1.75
1.75
MI-40
MR-52-2RS
3.25
4.25
1.75
2.66
MI-42
MR-52-2RS
3.25
4.25
1.75
2.66
MI-44
MR-56-2RS
3.5
4.5
2
3.2
MI-46
MR-56-2RS
3.5
4.5
2
3.2
MI-47
MR-56-2RS
3.5
4.5
2
3.2
MI-48
MR-60-2RS
3.75
4.75
2
3.41
MI-50
MR-60-2RS
3.75
4.75
2
3.41
MI-52
MR-64-2RS
4
5
2
3.615
MI-54
MR-64-2RS
4
5
2
3.615
MI-56
MR-68-2RS
4.25
5.25
2
3.995
MI-58
MR-68-2RS
4.25
5.25
2
3.995
MI-60
MACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SSMACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SSMACHINED TYPE Needle Thrust Bearing MR-12 MR12.2RS MR-12-2RS MR12SS
