Specifications
Brand Name :
SFT
Model Number :
6003ZZ
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000PCS/MONTH
Delivery Time :
20-45DAYS
Packaging Details :
carton,pallet
Material :
Bearing Steel
Seals Type :
open,ZZ, 2rs
ball material :
steel
Weight :
0.04KG
Number of Row :
Single row
Bore Size :
8 - 35 mm
Description

Deep Groove Ball Bearing 6003ZZ High Temperature Resistance

Product Description

Deep groove ball bearing is one of the most widely used rolling bearings. It is characterized by small friction resistance and high speed. It can be used to bear radial load or combined load of radial and axial at the same time. It can also be used to bear axial load.

The basic deep groove ball bearing consists of an outer ring, an inner ring, a group of steel balls and a group of retaining frames.
There are two types of deep groove ball bearings:Single row and Double row. The structure of deep groove ball can be divided into sealed and open type. Open type means that the bearing does not have a sealed structure. Sealed deep groove ball can be divided into dust-proof seal and oil-proof seal.
Compared with other types, deep groove ball bearing is easy to achieve higher manufacturing accuracy due to its simple structure, so it is convenient for series mass production with low manufacturing cost and widely used. Deep groove ball bearing can be used for gearbox, instrument, motor, household appliances,internal combustion engine, traffic vehicles, agricultural machinery, construction machinery, engineering machinery.

Feature:

1. High temperature resistance, with high glass transition temperature and melting point (334℃), its load thermal deformation temperature is up to 316℃, continuous use temperature is 260℃;

2. Superior sliding characteristics, suitable for use with strict requirements for low friction coefficient and wear resistance;

3. Hydrolysis resistance, continuous use in high temperature and high pressure water can still maintain excellent characteristics;

4. Radiation resistance; 5. Fatigue resistance; 6. Corrosion resistance

7. Solubility resistance

8. Good wear resistance, anti-static electrical insulation performance

Pls check the following size for bearing inside:

Model

Inner Diameter(mm)

Outside Diameter (mm)

Width(mm)

Weight (KG)

608ZZ

8

22

7

0.012

6000ZZ

10

26

8

0.019

6001ZZ

12

28

8

0.022

6002ZZ

15

32

9

0.031

6003ZZ

17

35

10

0.04

6004ZZ

20

42

12

0.068

6005ZZ

25

47

12

0.078

6006ZZ

30

55

13

0.113

6007ZZ

35

62

14

0.148
