SA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White Zinc
SA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White Zinc
SA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White Zinc
SA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White Zinc
SA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White Zinc
SA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White Zinc
SA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White Zinc
SA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White Zinc
Specifications
Brand Name :
SFT
Model Number :
SA 5-30 T / K
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000PCS/MONTH
Delivery Time :
20-45DAYS
Packaging Details :
carton,pallet
Material :
Steel, stainless steel, copper
Feature :
loaded slot,heavy duty
Weight :
0.03KG
Cage :
Steel Cage.copper Cage.nylon Cage
Operating Temperature Range(℃) :
-20~80
Surface Hardness :
HRC60-62
Description

rod end spherical sliding bearing and forged rod end bearing

Product Introduction:

Joint bearing is a kind of spherical sliding bearing. Its sliding contact surface is an inner sphere and an outer sphere. When moving, it can rotate and swing at any angle. It uses a variety of special processes such as surface phosphating, fried mouth, pad, and spray. Made of. Joint bearings have the characteristics of large load capacity, impact resistance, corrosion resistance, wear resistance, self-adjusting heart, and good lubrication.

Feature:

1. Design – Elimination of the guide ring allowed for a design change that improves cage balance and strength.
2. Material Technology – HPS series is made from high-cleanliness Z steel. Special surface treatment of spherical roller bearing increases resistance to wear.
3. Offer advanced material options: Super TF and TL steel, depending on application requirements.
4. Advanced Technology - patented Molded Oil lubrication system is also available.
5. Bearings are also available with an oil groove and holes in the outer ring for re-lubrication purposes. Optional inner ring oil groove and holes available.

Application:

Joint bearings are widely used in engineering hydraulic cylinders, forging machine tools, engineering machinery, automation equipment, automobile shock absorbers, water Conservancy machinery and other industries.

supply all kinds of rod end bearings with all dimensions as customers require, such as: SI...E, SI...ES, SA...E, SA...ES, SI...T/K, SA...T/K, SI...B/K, SA...B/K. GIR...UK, GAR...UK, PHS...., POS...., SIZP...S, SAZP...S, SIZJ...., SAZJ...., GIHR...DO, GIHR...K...DO, SIQG...ES, GK...DO, GF...DO, ect. The material of the bearings can be steel/steel, steel/PTFE bronze composite, steel/bronze

Style Inner Diameter Outside Diameter Thickness Weight
SA5T 5mm 18mm 8mm 0.013kg
SA6T 6mm 20mm 9mm 0.02kg
SA8T 8mm 24mm 12mm 0.038kg
SA10T 10mm 28mm 14mm 0.055kg
SA12T 12mm 32mm 16mm 0.085kg
SA14T 14mm 36mm 19mm 0.14kg
SA16T 16mm 42mm 21mm 0.21kg
SA18T 18mm 44mm 23mm 0.29kg
SA20T 20mm 50mm 25mm 0.38kg
SA22T 22mm 54mm 28mm 0.48kg
SA25T 25mm 60mm 31mm 0.64kg
SA28T 28mm 66mm 35mm 0.8kg
SA30T 30mm 70mm 37mm 1.1kg
SA35T 35mm 81mm 43mm 1.64kg

SA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White ZincSA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White ZincSA18T / K Rod End Spherical Sliding Bearing - Forged Rod End Bearing Coated With White Zinc
