Stainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal Joints
Stainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal Joints
Stainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal Joints
Stainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal Joints
Stainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal Joints
Stainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal Joints
Stainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal Joints
Stainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal Joints
Specifications
Brand Name :
SFT
Model Number :
POS16
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000PCS/MONTH
Delivery Time :
20-45DAYS
Packaging Details :
carton,pallet
Material :
Stainless steel
Port Size :
4mm-16mm
Size :
1/8-1/2
Application :
AXIAL SCX10 1/10 RC Crawler Car
Operating Temperature Range(℃) :
-20~80
Surface Hardness :
HRC60-62
Description

fisheye joint rod ends bearings connecting rod universal joints

Product details

FeatureEasy to connect/disconnect tube by one touch
PC type is useful for piping in confined space. given its six-angle wrench processing inside Eilliptical sleeve makes it possible to aplly and remove the tube easily in confined space Fittings are equipped with a Ciasket, O-ring on the thread.

Specifications1. fluid type: air (no other gases or liquids)
2. working pressure: 0 to I50psi
3. Negative pressure:-29.5 in Hg
4. Applicable tube: polyuerethane and nylon
5. Standard: Metric, Inch, NPT

Professional Service1. Trade Mark: ANRUK
2. Price Tenn: FOB Ningho or FOB Shanghai
3. Packing: Plastic Bag, Small Box, Carton
4. Leading time: 10-15 Days
5. transportation: By Sea or Air(Ningho or Shanghai)
6. Ccrtification: IS09001:2008

supply all kinds of rod end bearings with all dimensions as customers require, such as: SI...E, SI...ES, SA...E, SA...ES, SI...T/K, SA...T/K, SI...B/K, SA...B/K. GIR...UK, GAR...UK, PHS...., POS...., SIZP...S, SAZP...S, SIZJ...., SAZJ...., GIHR...DO, GIHR...K...DO, SIQG...ES, GK...DO, GF...DO, ect. The material of the bearings can be steel/steel, steel/PTFE bronze composite, steel/bronze

eight(kg)
C1 d B dk d2 max G6h h L1 MIN L2MAX R15 MIN a Dynamic Static
SA5T/K 6 5 8 11.11 18 M5*0.8 33 19 42 0.3 13 5.7 6.0 13 0.013
SA6T/K 6.75 6 9 12.7 20 M6*1 36 21 46 0.3 13 7.2 7.65 13 0.02
SA8T/K 9 8 12 15.875 24 M8*1.25 42 25 54 0.3 14 11.6 12.9 14 0.038
SA10T/K 10.5 10 14 19.05 28 M10*1.5 48 28 62 0.3 13 14.5 18 14 0.055
SA12T/K 12 12 16 22.225 32 M12*1.75 54 32 70 0.3 13 17 24 13 0.85
SA14T/K 13.5 14 19 25.4 36 M14*2 60 36 78 0.3 16 24 31 16 0.14
SA16T/K 15 16 21 28.575 42 M16*2 66 37 87 0.3 15 28.5 39 15 0.21
SA18T/K 16.5 18 23 31.75 44 M18*1.5 72 41 94 0.3 15 42.5 47.5 15 0.29
SA20T/K 18 20 25 34.925 50 M20*1.5 78 45 103 0.3 14 42.5 57 15 0.38
SA22T/K 20 22 28 38.1 54 M22*1.5 84 48 111 0.3 15 57 68 15 0.48
SA25T/K 22 25 31 42.85 60 M25*2 94 55 124 0.3 15 68 85 15 0.64
SA28T/K 25 28 35 47.6 66 M28*2 103 62 136 0.3 15 86 107 15 0.8
SA30T/K 25 30 37 50.8 70 M30*2 110 66 145 0.3 17 88 114 17 1.1
SA35T/K 28 35 43 57.1 81 M35*3 140 85 180.5 0.3 16 1.64

Application :

Engineering hydraulic cylinders,Forging machines,Construction machinery, Auto shock absorber etc

Stainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal JointsStainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal JointsStainless Steel Fisheye Joint Rod Ends Bearings Connecting Rod Universal Joints
