MZ30 Sprag One Way Backstop MZ Cam Clutch Bearing 30*100*82mm for Heavy Duty
MZ30 Sprag One Way Backstop MZ Cam Clutch Bearing 30*100*82mm for Heavy Duty
MZ30 Sprag One Way Backstop MZ Cam Clutch Bearing 30*100*82mm for Heavy Duty
MZ30 Sprag One Way Backstop MZ Cam Clutch Bearing 30*100*82mm for Heavy Duty
MZ30 Sprag One Way Backstop MZ Cam Clutch Bearing 30*100*82mm for Heavy Duty
MZ30 Sprag One Way Backstop MZ Cam Clutch Bearing 30*100*82mm for Heavy Duty
Specifications
Brand Name :
SFT
Model Number :
MZ30
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000PCS/MONTH
Delivery Time :
20-45DAYS
Packaging Details :
carton,pallet
Applicable Industries :
Manufacturing Plant, Machinery Repair Shops
Bore Size :
10 - 30 mm
Precision Rating :
P0
Number of Row :
Single Row
Type :
BALL
Seals Type :
Sealed
Product name :
MZ30 Sprag One Way Clutch
Material :
Chromel steel (Gcr15)
Size :
30*100*82mm
Description

MZ30 Sprag One Way Backstop MZ Cam Clutch Bearing 30*100*82mm

Technical Datas

Item MZ30
Material GCr15
Bore dia. 30 mm
Outer dia. 100 mm
Width 82 mm
Torque capacity 735 N.m
Drag torque 0.39 N.m
Weight 3.7 kg
Package Carton box, wooden box or as your requirements

Dimensions and Capacities

Model Capacity
Torque
(Nm)		 Torque
Drag
(Nm)

Over

running
(r/min)

Max.
Inner

Race

Over

running
(r/min)

Max.
Outer

Race

indexing
Max.
(cycle

/min)

Bore Size
Dia

(H7)

Key

way

 A B C PCDD

(M6)

E

 F G

H-M No.

of Tapped x
HolesSize×

Pitch

 S Wt
(kg)
MZ15 186 0.20 2,200 900 150 15 5*2.3 62 68 60 58 47 25 5.5 6*M5*P0.8 10 1.4
MZ17 215 0.20 2,000 800 150 17 5*2.3 66 75 64 64 52 28 6.3 6*M5*P0.8 10 1.8
MZ20 323 0.29 1,900 700 150 20 6*2.8 67 80 65 68 55 30 7.6 6*M6*P1.0 12 2.0
MZ30-22 735 0.39 1,800 500 150 22 6*2.8 82 100 80 88 75 45 8.9 6*M8*P1.25 16 3.7
MZ30-25 735 0.39 1,800 500 150 25 8*3.3 82 100 80 88 75 45 8.9 6*M8*P1.25 16 3.7
MZ30 735 0.39 1,800 500 150 30 10*3.3 82 100 80 88 75 45 8.9 6*M8*P1.25 16 3.7
MZ35 1,080 0.49 1,700 300 150 35 10*3.3 87 110 85 95 80 50 8.7 6*M8*P1.25 16 4.8
MZ45-40 1,620 0.69 1,700 300 150 40 12*3.3 92 125 90 110 95 60 8.4 8*M8*P1.25 16 6.2
MZ45 1,620 0.69 1,700 300 150 45 14*3.8 92 125 90 110 95 60 8.4 8*M8*P1.25 16 6.2
MZ60-50 2,110 0.98 1,600 250 150 50 14*3.8 102 155 100 140 125 80 9.1 8*M8*P1.25 16 10.2
MZ60-55 2,110 0.98 1,600 250 150 55 16*4.3 102 155 100 140 125 80 9.1 8*M8*P1.25 16 10.2
MZ60 2,110 0.98 1,600 250 150 60 18*4.4 102 155 100 140 125 80 9.1 8*M8*P1.25 16 10.2
MZ70-65 3,040 1.27 1,300 250 150 65 18*4.4 105 175 103 162 145 95 8.6 8*M8*P1.25 16 13.2
MZ70 3,040 1.27 1,300 250 150 70 20*4.9 105 175 103 162 145 95 8.6 8*M8*P1.25 16 13.2
