Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units
Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units
Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units
Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units
Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units
Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units
Specifications
Brand Name :
SFT
Model Number :
KFL001 bearing
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
50000PCS/MONTH
Delivery Time :
20-45DAYS
Packaging Details :
carton,pallet
Applicable Industries :
Manufacturing Plant, Machinery Repair Shops, Machinery parts
Type :
Pillow Block
Model NAME :
KFL001 flange Zinc Alloy bearing units
Length :
63 mm
Housing type :
FL001
Bearing type :
K001
Weight :
0.041 KG
Bearing material :
GCR-15
Housing Material :
Zinc Alloy pillow block
Description

Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units

Product Description

12mm FL001 KFL001 flange Zinc Alloy bearing units introduction :

Flange Zinc Alloy bearing units is a new type of bearing, to join other elements for zinc based alloy bearing.Often add alloy elements are aluminum, copper, magnesium, cadmium, lead, titanium, etc.Zinc base alloy low melting point, good liquidity, easy fusion welding, brazing and plastic processing, in the atmosphere corrosion, deformed material easy to recycle and remelting;But low creep strength, prone to natural aging changes size.The melting method, die casting and pressure processing timber.According to the manufacturing process can be divided into cast zinc-base alloy and deformation of zinc base alloy.

Standard Pillow Block Units : Light, Medium & Heavy Duty Series
• Pillow Blocks
• Flange Units
• Cartridge Units
• Take up Units
• Hanger Bearings Units
• Framed Take-up Units

Stainless Steel Series :
• Stainless Housing & Inserts
• Recommended for Food & Chemical Industries

Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units

Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units

KFL001 flange Zinc Alloy bearing units models series:

Bearing Unit NO. Shaft Dia d Dimensions(mm) Bearing No. Housing No. Housing
Wt (kg)
(mm) a e i g l s b z Bi n
KFL000 10 60 45 5.5 5.5 11.5 7 36 15.5 14 4 K000 FL000 0.032
KFL001 12 63 48 5.5 5.5 11.5 7 38 16 14.5 4 K001 FL001 0.041
KFL002 15 67 53 6.5 6.5 13 7 42 18.6 16.5 4.5 K002 FL002 0.05
KFL003 17 71 56 7 7 14 7 46 19.5 17.5 5 K003 FL003 0.068
KFL004 20 90 71 8 8 16 10 55 23 21 6 K004 FL004 0.104
KFL005 25 95 75 8 8 16 10 60 24.5 22.5 6 K005 FL005 0.11
KFL006 30 112 85 9 9 18 13 70 27 24.5 6.5 K006 FL006 0.168

UCP200 series pillow block bearing series :

Bearing Unit Shaft Dia. Dimensions(mm) Bearing No. Housing No. Weight(kg)
d(mm) h a e b s g w Bi n
UCP201 12 30.2 127 96 38 19 15 62 31.0 12.7 UC201 P201 0.63
UCP202 15 30.2 127 96 38 19 15 62 31.0 12.7 UC202 P202 0.61
UCP203 17 30.2 127 96 38 19 15 62 31.0 12.7 UC203 P203 0.59
UCP204 20 33.3 127 96 38 19 15 65 31.0 12.7 UC204 P204 0.61
UCP205 25 36.5 140 105 38 19 16 70 34 14.3 UC205 P205 0.74
UCP206 30 42.9 165 121 48 21 18 83 38.1 15.9 UC206 P206 1.15
UCP207 35 47.6 167 126 48 21 19 92 42.9 17.5 UC207 P207 1.40
UCP208 40 49.2 184 136 54 21 19 98 49.2 19.0 UC208 P208 1.78
UCP209 45 54.0 190 146 54 21 20 106 49.2 19.0 UC209 P209 2.00
UCP210 50 57.2 206 159 60 25 22 112 51.6 19.0 UC210 P210 2.55
UCP211 55 63.5 219 171 60 25 22 126 55.6 22.2 UC211 P211 3.2
UCP212 60 69.8 241 184 70 25 25 137 65.1 25.4 UC212 P212 4.4
UCP213 65 76.2 265 203 70 29 27 150 65.1 25.4 UC213 P213 5.1
UCP214 70 79.4 266 210 72 31 27 156 74.6 30.2 UC214 P214 5.7
UCP215 75 82.6 275 217 74 31 28 163 77.8 33.3 UC215 P215 6.3
UCP216 80 88.9 292 232 78 31 30 175 82.6 33.3 UC216 P216 7.6
UCP217 85 95.2 310 247 83 31 32 187 85.7 34.1 UC217 P217 9.2
UCP218 90 101.6 327 262 88 33 34 200 96.0 39.7 UC218 P218 11.4

Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units

Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units

Pillow Block Bearing 12mm FL001 KFL001 Flange Zinc Alloy Bearing Units
