Specifications
Brand Name :
CMCC
Model Number :
Fence Semi Trailer
Certification :
ce
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
5000 units/month
Delivery Time :
45 working days
Packaging Details :
Nude pack, with wax before shipment.
Use :
Truck Trailer
Material :
Steel
Max Payload :
60T
Function :
Transport sand, coal or stone
Axle :
Fuwa Brand with air suspension
Suspension System :
Mechanical Supension
Capacity :
Capacity
Side board :
6 mm
OE NO. :
HJGMCK20025
Main Beam :
T700/Q345 Steel
Color :
Customers Optional
Tire :
12.00R20
Floor board :
Floor board
Description

Cargo Semi Trailer 80 tons Side Dump Tipping Truck Hydraulic Double

Company Introduction

ZHUMADIAN CIMC HUAJUN VEHICLE CO., LTD., a joint venture company, located in ZHUMADIAN, HENAN, with convenient transportation, is a wholly-owned subsidiary of CIMC, one of the most important factories in CIMC VEHICLE GROUP. CIMC VEHICLE GROUP, as one of the nine CIMC major business sectors, owns 22 production bases over the world, producing capacity for all kinds of special vehicles and trailers is more than 0.2 million, which comes to the world leadership position.
CIMC HUAJUN covers an area of 0.8 million square meters, total assets of RMB 1.6 million, and about 2000 employees. The main products are semi-trailers, dump trucks, tank trailers, box trailers, refrigerator trucks or trailers, special purpose vehicles, etc. annual production capacity of more than 50,000.00 units.

Product Description

Specification
size overall size:13500*2650*3700mm
inner size:13350*2470*1800mm
body sheet side wall thickness: 3mm, floor thickness:4mm
chassis Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345, welded by
automatic Submerged-Arc processes.
axle 16T Axle, without ABS
tyre 1200R20
rim 8.5-20
leaf spring 90mm width*12pieces*16mm
suspention CIMC HUAJUN type
side beam 18# channel steel
braking system 2-line air braking system with air tank, WABCO emergency relay valve, braking chambers and
mechanical slack adjusters.
electrical system 24-volt electrical system.LED lights, 7-pin electrical connector.parking .stop, reverse, number plate
and indicator lights. rear lights conform to European standards, rear front, and side reflectors
Shotblasting and
paint
The chassis is completely shot-blasted to SA 2.5 grade and painted with the first layer of international Zinc
Epoxy primer(30 Microns DEF),second layer international high built polyurethane undercoat(40
microns DFT), THIRD AND FORTH LAYERS INTERNATIONAL alkyd FINISH TOP coat.total 80-100
microns. high quality painting. The whole trailer waxed.
landing gear 28T, two sides operation
Chamber T30/30 on front and middle axle, T30/ on rear axle
kingpin 90# Bolted type
Cylinder Domestic Cylinder
toolbox HUAJUN standard

Our Service

So far, we have visited more than 60 countries and regions to investigate the market demand and road conditions and set up offices in many countries to make after-sales service more timely and easy.

In addition, we built the KD plant in Djibouti in 2018, which mainly serves the assembly of trailers for customers in African areas and provides technical and operational guidance

Our Main Markets

With more than 60 years of unremitting efforts to make “HUAJUN” a well-known brand all over the world, products sold very well in China and also exported to more than 40 countries and regions, such as Southeast Asia, Africa, the Middle East, South America, etc.

With annual output of 50000 units of trailer, top 500 in the Chinese mechanical industry, and top 100 in the Chinese automobile industry, witness our great strength.

Pic

80 Tons Hydraulic Dumper Tipper Truck Double Side Cargo Semi Trailer

Our Supplier

Packing&Shipping

CIMC Group HUAJUN Vehicle 3 Axles Fence Cargo Semi Trailer 60 80 tons with Container Twist Lock

1. One unit was shipped separately or two/three units were packed together.

2. Naked or waxed both are acceptable.

the Carton Fair Exhibition

from 2007 to 2019 we went to the exhibition twice one year, maybe you are familiar with these faces.

Factory History

ZHUMADIAN CIMC HUAJUN VEHICLE CO., LTD., a joint venture company, located in ZHUMADIAN, HENAN, with convenient transportation, is a wholly-owned subsidiary of CIMC, one of the most important factories in CIMC VEHICLE GROUP. CIMC VEHICLE GROUP, as one of the nine CIMC major business sectors, comes to the world leadership position.

CIMC HUAJUN covers an area of 1.8 million square meters, total assets of USD 1.3 billion, about 2000 employees. The main products are semi-trailers, dump trucks, tank trailers, box trailers, refrigerator trucks or trailers, special purpose vehicles, etc. annual production capacity of more than 65,000.00 units.
