Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product
Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product
Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product
Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product
Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product
Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product
Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product
Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product
Specifications
Place of Origin :
Shanghai,China
Model Number :
JC-600/S400
MOQ :
1pc
Price :
100
Packaging Details :
standard export wooden case
Delivery Time :
15-20 working days
Payment Terms :
by T/T
Certification :
CE
Supply Ability :
100000pcs
Name :
needle detector,metal detector
model :
conveyor metal detector
Detection height :
180-500mm by customer's optional
Detection width :
600mm
HS code :
85437091
Model :
High accuracy model
alarm :
pilot lamp flash with alarm and conveyor stop
Auto rejection :
By customer optional
Description

needle detector, metal detector, needle detectors, industrial metal detector, automatic metal detector, metal detector machiner, metal detector equipment, tunnel metal detector,belt metal detector,garment needle detector,garment metal detector,apparel needle detector,sock metal detector,sock needle detector,shoes metal detector,shoes needle detector,toy metal detector,toy needle detector,textile metal detector,textile needle detector,cloth metal detector,cloth needle detector,needle detection machine,metal detection machine,needle check,metal check,check needle,check metal,find metal,find needle,digital metal detector, electronic metal detector,broken needle

Special height needle detector machine JC-600S/400

Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product

【Main features】

1. Stronger magnetic detection head, Super height for big product inspection.

2. Cycled,9 pairs of sensor, excellent anti-disturbance performance.

3. ABS plastic shell. Based on LED bar displayed control panel.

4. Smart auto counter. Count the alarm and pass numbers automatically.

5. Hi accuracy detection locating technology, LED indication for alarm location remind.

6. Alarm functions can be divided into three types, buzzer sound, lamplight flash and conveyor stop or belt return.

7. Optional conveying mode after alarm ;Optional automatical restart.

8. Reliability mechanical frame design, Hi stable during detection.

9. Designed for universal AC power supply, switch power supply.

Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product

【Range of Application】

It can be used for big product or package underwear, shirts, knitted sweaters, garments, shoes, socks, toys, carton, chemical, rubber, plastic, aluminum foil and others packaged products.

【SPECIFICATIONS】

Model: JC-600S-400
Detection tunnel width: 600mm
Detection tunnel height: 200mm/250mm/300mm/350mm/400mm/450mm
Conveyor belt width : 570mm
Max capacity: 20kgs
Motor output : 200W
Speed(m/min): 25m/m
Display/Operation Panel LED display with button design
Display/Operation Language English/Chinese
Alarm method: Alarm and lamp flash to stop transfer
Conveyor belt: Flat PVC belt
Power: AC110V/220V 50-60hz
Net Weight:200-250kgs 250kgs

Needle Detector,metal detector JC-600S speicial model(stronger detection head )for speical height product

【Series Standard】

Model Tunnel width Tunnel height Detection sensitivity
JC-600/200 600MM 80MM Fe, Steel ball≧1.0mm
JC-600/300 600MM 100MM Fe, Steel ball≧1.5mm
JC-600/400 600MM 150MM Fe, Steel ball≧ 2.0mm
JC-600/450 600MM 200MM Fe, Steel ball≧2.5mm

More info pls refer http://www.bjtoptech.com
