Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant
Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant
Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant
Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant
Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant
Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant
Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant
Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant
Specifications
Brand Name :
SHAN CABLE
Model Number :
YCW
Certification :
KEMA/CE/TUV/ISO/RoSH
Place of Origin :
SHANGHAI CHINA
MOQ :
500m
Payment Terms :
L/C, T/T
Supply Ability :
6542000m/week
Delivery Time :
7-10 days
Packaging Details :
wooden drum
Insulation :
EPR
Jacket :
CPE
Conductor :
Flexible Copper (claass5)
Standard :
60245IEC66
Conductor Temp :
65 Degree
Cable Size :
From 0.75mm2 to 300mm2
Corporation :
shenghua group
Brand :
Sh Cable
Description

Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant

Construction:

Conductor: Flexible Class 5 Copper Conductor
Insualtion: Rubber Sheath
Sheath: Rubber Sheath


Application :
This flexible power cable can be installed either as a fixed or mobile cable under adverse conditions such as in oily, acidic or alkaline environment

Insulation Color:
Single-Core: Black,
2-Core: Brown & Black,
3-Core: Brown, Blue & Green/Yellow
4-Core: Brown, Blue, Black & Green/Yellow
5-Core: Brown, Blue, Black, Grey & Green/Yellow


Voltage Class:300/500V
Rated Temperature: Continuous working temperature under 70°C is allowed for the conductor
Standard: CCC is according with IEC60245-4 standard
CE is according with the EMC regulations of 2004/108/EC (low voltage procedures) the provisions of CE
Conductor Material: Stranded flexible fine twisted copper wire
Insulation Structure:Rubber or EPR
Core Wire Type: Centralized accordant
Sheath Material:Rubber or Neoprene
Application: This middle duty rubber cable is applied to the power connecting cable of electrical equipment and small electric tools

Package: Soft packing of a knitted woven cloth, carton, wooden plate or iron plate

Cross-Sectional
Area mm2		Number diameter of coreOverall DiameterMax.D.C resistance
of at 20℃
MΩ/km		Approx Weight
(kg/km)
minmax
2x0.316/0.154.35.869.271.23031.5
2x0.528/0.154.86.43940.14345.5
3x0.316/0.154.66.169.271.23638.5
3x0.528/0.155.16.73940.17477


Black Heavy Rubber sheathed Cable EPR Insulated CPE Fire Resistant
