Flexible Copper Chlorinated Polyethylene Insulated EPR Rubber Sheath Cable
Flexible Copper Chlorinated Polyethylene Insulated EPR Rubber Sheath Cable
Flexible Copper Chlorinated Polyethylene Insulated EPR Rubber Sheath Cable
Flexible Copper Chlorinated Polyethylene Insulated EPR Rubber Sheath Cable
Flexible Copper Chlorinated Polyethylene Insulated EPR Rubber Sheath Cable
Flexible Copper Chlorinated Polyethylene Insulated EPR Rubber Sheath Cable
Specifications
Brand Name :
Shancable
Model Number :
H07RN-F YC YCW, H05RN-F
Certification :
CE KEMA
Place of Origin :
China
MOQ :
500
Price :
USD0.9-200
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
50000/month
Delivery Time :
10 working days
Packaging Details :
Wooden drum
Conductor :
Flexible Copper or tinned Copper
Insulation :
CPE(Chlorinated Polyethylene)
Sheath :
chloroprene rubber
Application :
Portable machine conntect
Standard :
60245IEC66
Cable core :
3-5
Corporation :
shenghua group
Brand :
Sh Cable
Description

Flexible Copper Chlorinated Polyethylene Insulated EPR Rubber sheath cable

Construction:

Conductor: Flexible copper or tinned copper conductor Class 5

Insualtion: CPE Rubber Sheath

Sheath: EPR Rubber Sheath

Application :


For portable machine, Also can be installed either as a fixed or mobile cable under adverse conditions such as in oily, acidic or alkaline environment

Insulation Color:


Single-Core: Black,
2-Core: Brown & Black,
3-Core: Brown, Blue & Green/Yellow
4-Core: Brown, Blue, Black & Green/Yellow
5-Core: Brown, Blue, Black, Grey & Green/Yellow

Sheath Color:


Black

Rubber sheathed flexible cable wire:

Flexible Copper Chlorinated Polyethylene Insulated EPR Rubber Sheath Cable

Working temperature

H07RN-F model rated voltage U0/U IS 450/750V

H05RN-F model rated voltage U0/U IS 300/500V

H05RR-F model rated voltage U0/U IS 300/500V

Long time allow working temperature of wire core cant be higher than 60

Rubber copper wire Working Conditions

1. Rated voltage :300/500(h05rn-f type),450/750V(h07rn-f type)

2. The long-term working temperature of conductor should be no longer than 65°C

3. W type cables have weather-proof character and certain grease-proof character and are suitable for outdoor usage and the occasion with greasy dirt.

4. ZR type cables have fire-retardant character.

Cross-Sectional
Area mm2		 Number diameter of core Overall Diameter Max.D.C resistance
of at 20℃
MΩ/km		 Approx Weight
(kg/km)
min max Copper Tinned-Copper YZ YZW
2x0.75 24/0.2 5.7 7.4 26 26.7 81.7 89.6
2x1 32/0.2 6.1 8 19.7 20 123 138
2x1.5 16/0.25 7.6 9.8 13.3 13.7 185 196
2x2.5 28/0.25 9 11.6 7.98 8.21 234 252
2x4 56/0.3 10.6 13.7 4.95 5.09 255 276
2x6 84/0.3 11.8 15.1 3.3 3.39 356 371
3x0.75 24/0.2 6.2 8.1 26 26.7 97.4 105
3x1 32/0.2 6.5 8.5 19.7 20 112 126
3x1.5 16/0.25 8 10.4 13.3 13.7 156 174
3x2.5 28/0.25 9.6 12.4 7.98 8.21 204 2019
3x4 56/0.3 11.3 14.5 4.95 5.09 285 302
3x6 84/0.3 12.6 16.1 3.3 3.39 398 423
4x0.75 24/0.2 6.8 8.8 26 26.7 117 125
4x1 32/0.2 7.1 9.3 19.7 20 134 148
4x1.5 16/0.25 9 11.6 13.3 13.7 186 206
4x2.5 28/0.25 10.7 13.8 7.98 8.21 255 270
4x4 56/0.3 12.7 13.8 4.95 5.09 356 374
4x6 84/0.3 14 17.9 3.3 3.39 465 482

Packing and shipping

Flexible Copper Chlorinated Polyethylene Insulated EPR Rubber Sheath Cable
