Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding
Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding
Specifications
Brand Name :
Rise laser
Model Number :
RL-R1512
Certification :
ISO, ce
Place of Origin :
Shenzhen, China
MOQ :
1 set of this Machine
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 units/ month
Delivery Time :
5-9 working days
Packaging Details :
Wooden case
Number of axes :
6 axis
Payload :
10KG
Robot weight :
172KG
Application :
Metal Stainless Steel Laser Welder
Function :
Welding Steel Tube
Type :
Fully Automatic Cnc Welder
Welding Material :
Stainless Steel Carbon Steel Metal
Battery capacity :
4.5KVA
Warranty :
1 Year
Description

Automatic Fiber Laser Welding Robot Machine with 6 Axis Cobot Robot for 10KG Payload Industrial Robot Welding

Six-axis Robotic Arm Fiber Laser Welding Machine enables fast welding speeds, increasing efficiency and output. This can lead to faster manufacturing times and lower costs for enterprises. The performance of the six-axis industrial robot is stable, the robot’s stable performance is achieved through its precise control system, which ensures that the robot moves accurately and consistently during operation.

Parameters

Model
RL-R1512
Number of axes
6 axis
Radius of motion
1550mm
Payload
10KG
Degree of protection
J1, J2 axis IP56 (J3, J4, J5, J6 axis IP67)
Installation method
Floor, wall-mounted, tilted, upside-down
Battery capacity
4.5KVA
Input/output signal
Standard 16 in/16 out 24VDC
Robot weight
172KG
Repeatability
+0.05
Range of motion
1 axis S
±160°
2 axis L
+80 to -145°
3 axis U
+145° to -75°
4 axis R
+190°
5 axis B
+50 to -210°
6 axis T
±360°
Movement speed
1 axis S
257°/s
2 axis L
223°/s
3 axis U
223°/s
4 axis R
392°/s
5 axis B
275°/s
6 axis T
540°/s
Application field
Loading and unloading, spraying, handling, packaging, cutting
4 axis R(N.m)
103.5
5 axis S(N.m)
51.84
6 axis T(N.m)
32.64
Built-in trachea
Φ10
Installation environment
Temperature 0-45°C,Humidity 20~80%RH (no condensation) vibration acceleration below 4.9m/S (0.5G) altitude below 1000m
Other non-flammable, corrosive gases, liquids, no splashing water, less oil, dust away from electromagnetic sources and away from
magnetic fields

Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot WeldingAutomatic Fiber Laser Welding Machine With 6 Axis Industrial Robot WeldingAutomatic Fiber Laser Welding Machine With 6 Axis Industrial Robot WeldingAutomatic Fiber Laser Welding Machine With 6 Axis Industrial Robot WeldingAutomatic Fiber Laser Welding Machine With 6 Axis Industrial Robot WeldingAutomatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding

Automatic Fiber Laser Welding Machine With 6 Axis Industrial Robot Welding

FQA

1.How long is the warranty period?

Whole machine warranty period is 1 year, laser source 2 years. If there is any problem during the period, we will solve it as soon as possible. 2.How long is the cable?

Different laser source have different option. For example, the normal cable length of raycus and max is about 9 meters.

3.How thick can 1500w-3000W be welded

1-8mm thick metal materials.

4.Is there a wire feeder?

We have a wire feeder to choose from. If you are interested, you can contact us and provide your email address.We will send more detailed pictures to your email.

5.Can aluminum and galvanized steel be welded?

Yes, it can.

6.Packaging

All our machines are packed in wooden boxes.

7.Language interface

Supports language customization, etc. You can also translate and insert to software.
