IPG Photonics CW Fiber Laser For 2D & 3D Metal Cutting And Welding
IPG Photonics CW Fiber Laser For 2D & 3D Metal Cutting And Welding
Specifications
Brand Name :
Raycus
Model Number :
IPG YLS-U/CUT
Certification :
CE,ISO9001:2008
Place of Origin :
Shenzhen, China
MOQ :
1 PCS
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, D/P
Supply Ability :
2000 units per year
Delivery Time :
7 Work Days
Packaging Details :
Carton Case
Key word :
ipg photonics
Central Wavelength Range, nm :
1070 ±10
Mode of Operation :
CW/ Modulated
Modulation Frequency, kHz :
0-5
Maximum Average Power*, kW :
1, 2, 3, 4, 6
Power Tunability, % :
10-100
Power Stability**, % :
±0.5
Output Fiber Core Diameter :
50, 100 and 200 μm or Single-mode
Beam Mode Quality :
Multi-mode BPP mm × mrad: 2, 5, 10 Single-mode: M2< 1.1
1-3 kW weight :
<140
Description

The world's smallest kilowatt-scale fiber laser
YLR-U series is the industry's smallest kilowatt-class continuous ytterbium-doped fiber laser.
Offers record-breaking performance, an extremely compact form factor, and a high power-to-volume ratio.

Model YLR-1000-U YLR-1500-U YLR-2000-U YLR-3000-U YLR-6000-U
Central Wavelength Range, nm 1070 ±10
Mode of Operation CW/Modulated
Modulation Frequency, kHz Up to 50
Max. Average Power Mode, W 1000 1500 2000 3000 6000
Power Tunability, % 10-100
Power Stability, % ±0.5
Output Fiber Core Diameter 50, 100 and 200 μm or Single-mode**
Beam Mode Quality Multi-mode BPP mm × mrad: 2, 5, 10 Single-mode: M2< 1.1

IPG Photonics CW Fiber Laser For 2D & 3D Metal Cutting And Welding

Laser features

  • Average Power up to 6 kW* Up to >40% Wall-plug Efficiency
  • Extremely Small Size and Low Weight Built-in Diagnostics with Web Connectivity
  • Exceptional Operation in High Humidity Environment Single-mode Option up to 3 kW

Application

2D & 3D Metal Cutting and Welding Various Steels, Al, Cu, Ti Alloys, and Other Metals
High Speed Cutting Conduction and Keyhole Welding

IPG Photonics CW Fiber Laser For 2D & 3D Metal Cutting And Welding

IPG Photonics CW Fiber Laser For 2D & 3D Metal Cutting And Welding

Packages

IPG Photonics CW Fiber Laser For 2D & 3D Metal Cutting And Welding
