50HZ EPS Sandwich Panel Making Machine Continuous Cold Roll Forming
50HZ EPS Sandwich Panel Making Machine Continuous Cold Roll Forming
50HZ EPS Sandwich Panel Making Machine Continuous Cold Roll Forming
50HZ EPS Sandwich Panel Making Machine Continuous Cold Roll Forming
50HZ EPS Sandwich Panel Making Machine Continuous Cold Roll Forming
50HZ EPS Sandwich Panel Making Machine Continuous Cold Roll Forming
Specifications
Brand Name :
HENGRUIYANG
Model Number :
OEM ODM
Certification :
CE/ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1 sets
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
30 SETS/ MONTH
Delivery Time :
40 days after payment
Packaging Details :
Container
Production speed :
4-4.5m/min
Cutting blade material :
Cr 12 high grade steel
Voltage :
380V, 50HZ
Backboard Thickness of plate :
20mm
Chain Size :
20mm
Description

EPS Sandwich Panel Making Machine Continuous Cold Roll Forming 50HZ

Product Description

Technical specification

1. Technique parameters of the processing line

(1) Coil material: EPS, rock wool, glass silk floss and so on

(2) Thickness of the plate: 0.3-0.8mm

(3) Core thickness: 20-300mm

(4) Production capacity (according to your glue):

4-4.5m/min (the fastest), 2-2.5m/min(the slowest)

(5) Total power: about 30KW

(6) Weight: 25ton

(7) PLC control systerm, easy to operate, high precision and work stably.

(8) Dimensions of whole production line:

About Length35000mm × Width2500mm × Height2600mm

Components of line:

No. Name Unit Qty
1 Composite Decoiler set 1
2 Main Machine For Roll Forming set 1
3 Main Machine For Compositing set 1
4 Control System(PLC) set 1
5 Cutting System set 1
6 Runout Table set 1

Working Flow:

manual uncoiler - roll forming machine - computer control system - hydraulic control system - cutting system - output table

50HZ EPS Sandwich Panel Making Machine Continuous Cold Roll Forming

Our Services and Terms

Terms of Payment: 40% of the total contract value paid by T/T as down payment, the rest 60% of the total contract value to be paid by T/T after inspection by buyer in seller’s factory while before delivery.

Delivery: 60 days after receipt of advance payment

Service: we send technician to your country to fix the machine.The buyer should bear all the cost including: visa, Roundtrip tickets and suitable accommodation, also buyer should pay salary 60USD/day.

Warranty: 12 months limited warranty

During warranty: parts are free but buyer pay for the shipping fee

50HZ EPS Sandwich Panel Making Machine Continuous Cold Roll Forming
