Specifications
Place of Origin :
CHINA
Brand Name :
HONGRUN
Plastic Type :
PS
Product Type :
Fast Food Box
Power :
200KW
MOQ :
1SET
Price :
negotiation
Packaging Details :
Standard Export Packaging
Delivery Time :
90days
Payment Terms :
T/T, L/C
Supply Ability :
100SETS PER YEAR
Model Number :
HR-1040
Certification :
CE and ISO9001
Automatic :
fully automatic
Plastic type :
PS
Warranty :
One Year
Application :
Food Container
Weight :
16T
After-sales service provided :
Engineers available to service machinery overseas
Product type :
Fast Food Box
Voltage :
380V/220V/415V 50/60Hz 3.0Kw
Condition :
New
Description

Touch Screen Control Foam Food Container Machine Hydraulic Pneumatic Servo Drive

Product Application

PS disposable take away food box making machine , which can form lunch box from raw material. The material is recycled. The work flow is as follows: raw material---(PS foam sheet extrusion line)---foam sheet---(lunch box forming machine and cutting machine)---lunch box---(plastic recycle machine)---plastic granulars( this part can be used as raw material)----foam sheet.

Touch Screen Control Foam Food Container Machine Hydraulic Pneumatic Servo Drive

1. PS foam sheet extruder machine

Touch Screen Control Foam Food Container Machine Hydraulic Pneumatic Servo Drive

PS foam sheet extruder machine uses a tandem screw technology to produce fine-block cell-structured extruded polystyrene foam sheet with high strength and a pearl and even surface, in a continuous roll, from polystyrene injection an eco-friendly blowing gas and additives. It has a user friendly operating system with inverter controlled driving, digital temperature control and so on. It produce PS foam sheet, which is a kind of new-type packing with the features of shock proofing, sound insulating, heat preservation, damp proof, safety, and good plasticity. It is used widely in the packing of food, fruit, electronic product, daily necessities, hardware product, advertisement plate, etc.

Technical data

Item Unit Parameter
Model 105/120
Applicable materials GPPS granule(123P/525)
Thickness of sheet mm 1-3.5
Width of sheet mm 540~1080
Foaming rate 12-20
Weight of product kg/m³ 50~83
Output kg/h 150~200
Rated power(approximately) KW 180
Power supply Three phase 380V/50Hz
External dimension mm 24000×4100×2800
Complete weight Ton About12

2.Fully Automatic Robot Arm Vacuum Forming Cutting And Stacking Machine.

Touch Screen Control Foam Food Container Machine Hydraulic Pneumatic Servo Drive

PS disposable foam food container/plate/dish/tray/bowl/box making machine makes different kinds type of fast food box, foam tray, foam plate, foam container and so on. If so, you need many moulds.
This type of developed by combining the domestic equipment and advantages, is a set of hydraulic pneumatic servo drive for an automatic forming cutting seek. Mainly by electrical components, Japan and Germany pump, ensure the reliability of the equipment operation, and can be used for hot forming process many kinds of plastic material, it can produce PS packaging products, materials used in food, medical supplies, electrical components, tourism products, toys, textile, etc.
The biggest advantage is forming cutting integration, reduce work link, produce the product directly, it can be collected in stacking area of work to save time, save the production base and greatly reduces the working intensity save artificially

Technical data

Item Unit Parameter
Model HR-L1080
Power supply Three phase 380V/50Hz
Production efficiency s/mold 2.8-5
Installed power (approximately) KW 250
Total weight (approximately) Ton 18
Mounting size m 14.2×5.8×3.14
Compressed air capacity m3/min 0.4～0.7
Compressed air pressure Mpa 0.7
Cooling water T/h 1

Touch Screen Control Foam Food Container Machine Hydraulic Pneumatic Servo Drive

3. PS scrap recycling and pelletizing machine.

This recycling and pelletizing machine is designed to reclaim the foamed polystyrene andpolyethylene materials almost identically to new ones with its own superior filtering performance.
