Fully Automatic M Door Frame Making Machine
Fully Automatic M Door Frame Making Machine
Fully Automatic M Door Frame Making Machine
Fully Automatic M Door Frame Making Machine
Fully Automatic M Door Frame Making Machine
Fully Automatic M Door Frame Making Machine
Specifications
Brand Name :
DBKJ
Model Number :
DBKJ-DF
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
30 sets per month
Delivery Time :
within 45 days after receiving the deposit
Packaging Details :
Export package
Work Pressure :
550mpa-350mpa
Production Capacity :
25m/ min
Voltage :
380V/50HZ 3Phase
Power :
8.5 kw
Description

Fully automatic door M Door frame making machine

Product Description

Fully automatic M door frame making machine can rollform different kind’s metal door or window frames, reinforced, fire stop doors, etc. The punching also can be designed according to your needs, for some type of punching we will do before rolling forming, for some types we do after rolling forming. After roll formed by this roll forming machine, the surface will be very smooth and beautiful without any scratch on surface

Compared with traditional door frame making machine, this one is fully automatic, it allows you to do bending and then finish the connection of the door frame jamb, and side door frame. No need welding, here are some drawing profiles for your reference:

Fully Automatic M Door Frame Making MachineFully Automatic M Door Frame Making Machine

Fully automatic M door frame making machine Process Flow:

Fully Automatic M Door Frame Making Machine

Fully automatic M door frame making machine design parameters:

No. Name and features Quantity
1 5 Ton hydraulic decoiler 1
2 M door frame rolling machine 1
3 Punching device 1
4 Shearing system 1
5 Gerabox transmission 1
6 PLC 1
7 Hydraulic station 1
8 Receiveing table 2

How to do the installation of the metal door frame made by this machine:

Fully Automatic M Door Frame Making MachineFully Automatic M Door Frame Making Machine

Fully Automatic M Door Frame Making Machine

Forming device

Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, gearbox transmission,roller was chromed which can keep the molding plate surface smooth and not easy to be marked when it is working

Feature : Ensure stability , precision and lifetime.

Cutting device

Advanced hydraulic drive, automatic punching and cutting after forming, no distorting or wasting, high level safety factor. We will add the 45 shearing here to make the connection part more beautiful.

Blade Material Cutting system
Cr12 steel with quenched treated 60-62°C Full automatic
