Light Steel Roll Forming Machine for Modular Prefabricated Steel Frame House
Light Steel Roll Forming Machine for Modular Prefabricated Steel Frame House
Specifications
Brand Name :
Shenghong
Model Number :
SH18-01-04-03
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20 sets per month
Delivery Time :
Within 30 days after receiving the deposit
Packaging Details :
Export Package
Production Capacity :
15-55M/Min
Power :
4+4Kw
Voltage :
380V 50Hz 3Phases
Dimension(L*W*H) :
5000*800*1200Mm
Weight :
2.5T
thickness :
0.3-0.7mm
Warranty :
18Month
Description

Light Steel Roll Forming Machine for Modular Prefabricated Steel Frame House

Product Description

NO. Item Model Quantity
1 89*41*10mm 89*41*10mm 1
2 140*41*10mm 140*41*10mm 1
3 BD BD 1

Note: This production line can be put into one 40feet container.

The price is based on FOB SHANGHAI.

Application:

Light Steel Roll Forming Machine for Modular Prefabricated Steel Frame House

Light Steel Roll Forming Machine for Modular Prefabricated Steel Frame House

Production Flow

Uncoiling → Sheet Guiding → Holes Punching → Roll Forming → Cutting → Products Receiving

Roll Forming Line’s Specification

No. Item Specification
1 Powered Decoiler
Loading weight 3tons
Coil Inner Diameter 508mm
Power 1.5kw
2 Roll Forming Machine
Dimension 5Mx1Mx1.8M
Weight 3500KGS
Material of Rollers Material: GCr15
Processing Technic for Rollers CNC machining, heat treatment HRC58-60,then processed by CNC lathe, plating finally
Material of Shafts 40Cr
Processing Technic for Shafts CNC machining, quenching and tempering HRC28-32,then processed by CNC lathe, plating and polishing finally
Sheet Guiding Device Light Steel Roll Forming Machine for Modular Prefabricated Steel Frame House

Holes Punching Device

(dimpling with screw holes,service hole,web notch,lip notch, truss end chamfer, swage, crimp)
3 Control System
Main control system One Lenovo laptop and a control box inside of based frames of the machine
Producing software Special designed to match with the designing software Vertex
Leaser Printing Device USA Matthews Leaser Printing Device for painting spray logo and installation indicating number
Remote-control device Wireless remote-controller controls machine to go forward or backward or stop
Brands of main components PLC(self-developed),Relay (Schneider), proximity switch(Schneider), Encoder(Omron), Servo Motor(Xinjie)
4 Servo System and Hydraulic System
Servo motor 5.5kw, taking with precision planetary gear reducer
Hydraulic Station 7.5KW;Hydraulic oil injection 200 litre
5 Run-out Table
Length 3M

Training & Installation

1. We will dispatch technician to your facility for the installation and commissioning. The presence of your trainee is a must during our technician’s visit.

2. All the travelling, accommodation, local transport and food expenses, and allowance of our mechanical technician’s visit to your facility will be your responsibility.

3. Customer can dispatch his own engineer to supplier’s factory to learn how to use the software. Supplier affords two engineers’ accommodation for 10 days. Customer affords engineer’s round-trip tickets and visa cost.
