Specifications
Brand Name :
Shenghong
Model Number :
SWL151228-220
Certification :
CE ISO
Place of Origin :
Jiangsu, China
MOQ :
1 sets
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
25 SETS/ MONTH
Delivery Time :
40 days after payment
Packaging Details :
1. Export standard package for container 2. Host nude, wheels with oil and gas bubble cushion packaging. 3. PLC controller with bubble cushion packaging 4. Spare parts in wooden cases.
Upper and lower layer :
metal sheets or decorative polywood sheets
Middle :
Condensed polystyrene foam board
Over Dimension :
45000mm*3000mm*2800mm
Power supply :
AC380V; 50-60Hz; 3 Phase
Description

Hydraulic Powered Uncoiler Metal Roofing Forming Machine , Roof Sheet Making Machine

Sandwich Panel Machine Components:
Over Dimension 45000mm*3000mm*2800mm
Power supply AC380V; 50-60Hz; 3 Phase
Total power 32 KW
Working speed 7-12 m/ min
Formed sandwich panel width 1000mm; 1200mm
Formed sandwich panel thickness 50-300mm
Cover steel thickness 0.3-0.8mm
Core material EPS foam,XPS foam,PU, rock wool
Style Roof&wall panel
The PU sandwich panel line includes the following parts:
1.Hydraulic powered uncoiler
2.Film covering equipment
3.Roll forming machine
4.Preheating oven
5.Polyurethane foaming system
6.Double belt conveyor
7.Cutting device
8.Automatic stacker or Manual stacker (for option).
Sandwich Panel Machine Specifications (we can design as per buyer's special requirement ):
Panel width 1000mm
Panel thickness Mini thickness: 40mm (corrugated sandwich panel), 50mm (wall panel)
Max. Thickness: 150mm (corrugated sandwich panel), 200mm (wall panel)
Steel Sheet Specifications (we can design as per buyer's special requirement ):
Thickness 0.4-0.7mm color steel sheet
Width 1250mm
Max. Coil weight 5tons
Inner Dia. Of coil 508mm
Sandwich Panel Machine Line Specifications (we can design as per buyer's special requirement ):
Working speed max. 8m/min (adjustable)
Total length about 120m
Double belt conveyor 23m
Control mode Misubishi PLC
Pouring pressure 150-200Bar
Work height 1150mm
Stacking height 1000mm
Total power about 100Kw
Power required 380V/3phase/50Hz or as per customers requirement.

Machinery Shows

Hydraulic Powered Uncoiler Metal Roofing Forming Machine , Roof Sheet Making Machine
