Specifications
Brand Name :
Shenghong
Model Number :
SWL151227-214
Certification :
CE ISO
Place of Origin :
Jiangsu, China
MOQ :
1 sets
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
25 SETS/ MONTH
Delivery Time :
40 days after payment
Packaging Details :
1. Export standard package for container 2. Host nude, wheels with oil and gas bubble cushion packaging. 3. PLC controller with bubble cushion packaging 4. Spare parts in wooden cases.
Feature :
High Speed, Whole life technical support
Service :
customization available
Raw material :
Depends on profile
Yield strength :
≤ 400 Mpa
Number of stations :
16-25 stations
Depth of step :
10-30mm
Description

Elegant Style Steel Roof Sheet Forming Machine For Building / House

Technical parameters:


Number of stations: 16-25 stations
Length of step: 150-500mm
Depth of step: 10-30mm
Forming speed: 32 steps / min(flying press) or 20 steps / min
Steel thickness: 0.5-0.6mm
Roller material: 45# steel, coated with chrome
Main motor power: 5.5kw
Hydraulic cutting power: 4kw
Power supply: 380V 50HZ 3 phase
Tolerance: 1.5mm
Control system: PLC with touch screen

Description of roof tile roll forming machine:

  • The roofing tile products are formed by cold roll forming machine from high quality coated sheet, which performs the elegant style of traditional roof tile and suits for every architecture design.
  • With light, strong strength and long lasting quality, it is convenient and takes short time for installation.
  • The machine is for continuously roll forming and pressing step tiles on series of product profile.
  • The length can be set up or unlimited and the depth of each step is from 10 to 30mm adjustable.
  • This roofing tile roll forming line consists of hydraulic single head type uncoiler, roll forming main machine, hydraulic forming tile machine, hydraulic automatic cutting machine, products run out table, PLC automatic control cabinet.

Dlazed steel tile designed drawing


Elegant Style Steel Roof Sheet Forming Machine For Building / House

Producing process sketch of glazed steel tile roll forming machine


Elegant Style Steel Roof Sheet Forming Machine For Building / House

Technological process of glazed tile roll forming machine:


Uncoiling---Feeding---Leveling---Punching---Roll forming---Cutting---Products collecting


Typical glazed steel tile:


Elegant Style Steel Roof Sheet Forming Machine For Building / House Elegant Style Steel Roof Sheet Forming Machine For Building / House Elegant Style Steel Roof Sheet Forming Machine For Building / House
Green glazed steel tile Orange glazed tile Red glazed steel tile

Roof tile application:


Elegant Style Steel Roof Sheet Forming Machine For Building / House Elegant Style Steel Roof Sheet Forming Machine For Building / House Elegant Style Steel Roof Sheet Forming Machine For Building / House

Machinery Photos

Elegant Style Steel Roof Sheet Forming Machine For Building / House
