2.2 KW Down Pipe Downspout Elbow Machine Electrical Control System
2.2 KW Down Pipe Downspout Elbow Machine Electrical Control System
2.2 KW Down Pipe Downspout Elbow Machine Electrical Control System
2.2 KW Down Pipe Downspout Elbow Machine Electrical Control System
Specifications
Brand Name :
Shenghong
Model Number :
SWL151224-154
Certification :
CE ISO
Place of Origin :
Jiangsu, China
MOQ :
1 sets
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
30 SETS/ MONTH
Delivery Time :
40 days after payment
Packaging Details :
Container
Application :
Rectangular Downspout & Rain gutters , downpipe
Cutting motor :
2.2 KW ( 3XAC380v, 50HZ)
Roller material: :
High quality 40Gr after treating
Sheet Thickness: :
0.4 to 0.6 mm
Max bending angle: :
90
Machine functions: :
bending and locking function
Description

2.2 KW Down Pipe Downspout Elbow Machine Electrical Control System

Rectangular downspout elbow pipe Machine

Control mode:

motor power

Main power:

2.2KW

Max bending angle:

90

Machine functions:

bending and locking function

Bending speed:

20-25m/ min

Line size (Lx w x h)

1300 mm×650 mm×1500 mm

Square downspout roll forming machine components

  1. material feeding device
  2. main roll forming machine
  3. moulds pressing part
  4. mould cutting device
  5. electrical control system

Square Downspout Pipe Roll Forming Machine main parameters

Forming Roller Stations:

18 Stations

Forming Roller size:

36 mm (for soft quality sheet)

Forming Speed:

12 meters / min

Main motor:

3kw,

Hydraulic station power:

5.5kw

Capacity Width:

Less than 200mm

Material of Sheet:

Soft Quality (Annealed) Galvanized Sheet

Sheet Thickness:

0.5 to 0.6 mm

Line structure:

Portal-type frame style, 45# steel

Control mode

PLC

Total Gross Weight:

About 4000kgs

Line size (Lx w x h)

7000 mm×1000 mm×1100 mm

Shipment:

In 1 x 40 Feet containers

Roll Forming machine for Production of Drainpipe System

  1. The downspout roll forming machine is special for manufacturing various size square downspout, Downspout & Rain gutters, Downspipe, rectangular downspout pipes used for resident building or commercial building.
  2. Downspout or Down pipe is a pipe for conveying rain water from a roof or gutter to the ground or to a drain., also referred to as Leader pipe, Down-pipe or Drains-pout.
  3. The downspouts are more and more widely applied in rain water storage solution.

Rectangular Downspout Elbow Machine

  1. Elbows are fittings that attach to the downspout.
  2. One end of the gutter elbow is crimped so that it can fit inside another elbow or downspout.
  3. Elbows are used at the bottom of the downspout at ground level to direct drainage in a particular direction.
  4. Two elbows coming from the gutter are used to span the length of the eave so the downspout can be directly mounted to the wall of the structure.
  5. The square downspout line is designed according to profile drawing sent from client, thickness 0.4mm-0.6mm


Rectangular Downspout Elbow Profiles (Downspout Crimpers)



Roll Formed Profiles - Square (Rectangular) Downspout


Custom square Downspouts & Rain Gutters machines can be designed according to client’s requirements or downspipe sample.

Pipe Drawing Shows

Workshop Profiles
