Good Perfomance Low Labor Rolling Forming Machine 0.5mm - 1mm Thickness
Good Perfomance Low Labor Rolling Forming Machine 0.5mm - 1mm Thickness
Good Perfomance Low Labor Rolling Forming Machine 0.5mm - 1mm Thickness
Good Perfomance Low Labor Rolling Forming Machine 0.5mm - 1mm Thickness
Specifications
Brand Name :
Shenghong
Model Number :
SWL151231-229
Certification :
CE ISO
Place of Origin :
Jiangsu, China
MOQ :
1 sets
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
25 SETS/ MONTH
Delivery Time :
40 days after payment
Packaging Details :
1. Export standard package for container 2. Host nude, wheels with oil and gas bubble cushion packaging. 3. PLC controller with bubble cushion packaging 4. Spare parts in wooden cases.
Power Source :
Electric
Rollers Material :
No.45 Forged Steel with Hard Chrome
Feature :
Manual shearing device before material feeding
hydraulic decoiler :
5-8 tons
Material :
0.5mm-1mm
Description

Good Perfomance Low Labor Rolling Forming Machine 0.5mm - 1mm Thickness

Application


Our roof panel roll forming machine produces different kinds of steel panel tiles for roofs and walls. The roll formed tiles are primarily used for temporary building sites, steel structure workshops, and other public buildings and feature fast construction speed. Our tiles are durable, have an attractive appearance, etc.

Main Equipment


Our roof panel forming machine consists of a manual decoiler, feeding platform, main molding core, shearing machine, hydraulic station, computer control cabinet, high precision counter, and driven system protective covering panel supporting table.

Technical parameters of Roof Panel Roll Forming Machine

NO Model Coil Width (mm) Effective Width (mm) Profile Drawing
1 29-180-720 1000 720
2 35-125-750 1000 750
3 22-215-860 1000 860
4 3/4''-9''-36'' 40.875 '' 36''
5 24-83-913 1250 913
6 22-215-1075 1250 1075
7 32-196-980 1220 980
8 28-200-1000 1200 1000
9 44-150-900 1250 900

Technical Specifications of Roof Panel Roll Forming Machine

Item Description
Material Width 1000mm
Material Thickness 0.5mm-1mm
Material PPGI GI
Yield Stress 235Mpa
Material of Roller 45# steel plated hard chromium 0.05mm
Diameter of Shaft 70mm
Voltage AC380v/50hz or per customer's requirement
Motor Power 7.5kw
Hydraulic Power 4kw
Stand 18
Control System Mitsubishi PLC frequency conversion
Hydraulic Cutting Material Cr12 heat treatment
Speed 8-15m/min
Decoiler 5 tons manual or hydraulic

Technical Specifications of Roof Panel Roll Forming Machine

Item Description
Material Width 1250mm
Material Thickness 0.5mm-1mm
Material PPGI GI
Yield Stress 235Mpa
Material of Roller 45# steel plated hard chromium 0.05mm
Diameter of Shaft 70mm
Voltage AC380v/50hz or per customer's requirement
Motor Power 5.5kw
Hydraulic Power 4kw
Stand 18
Control System Mitsubishi PLC frequency conversion
Hydraulic Cutting Material Cr12 heat treatment
Speed 8-15m/min
Decoiler 5 tons manual or hydraulic

Features


This type of roof panel forming machine features high speed, high production, good performance, low labor and is economical. This roll former is the best choice for producing metal sheet cold roll formed products.

Flow chart


Decoiling the sheet---Guiding the sheet---Leveling the sheet---Roll forming---Punching the sheet---Measuring the length---Cutting the sheet---on the output table

Machine Placement and Operator


The roof panel roll forming machine should be placed on an even cement floor and lifted with a lifting device with a lifting capacity not less than five tons. The machine requires space for storing materials, laying the machine and enough room for it to operate. The roof panel roll former requires one operator and one porter. The temperature in the workspace should be no less than -14℃.

As an experienced roof panel forming machine manufacturer based in China, We produces an extensive line of forming equipment, such as curved roofing sheet roll forming machines, roll forming machines, metal sheet forming machines, and so on. We can manufacture our forming machine according to customers' specific requirements. As a result of our high quality products and dependable service, we have been awarded the ISO9001 certificate.

Machinery Photos

Workshop Show

Thank you for visiting our website. Please feel free to contact us for more information. We look forward to hearing from you.
