Main Components of Machine

1.PLC Control System for Steel Sheet Forming Line

• Control the quantity and cutting length automatically
• Combined with: PLC, Inverter, Touch Screen, Encoder, etc
• Control Voltage 24V

2.PU Foaming Line (including one Control System and one Bandsaw Cutting System):
Steel sheet heating system:12 groups of fluorescent lamp for heating(controlled by temperature controller)

PU foaming system consist of :

• A and B material feeding motor 2PCS, each one with 0.75KW;
• A and B material blending motor 2PCS, each one with 0.55KW;
• A+B material blending motor 1PC, with 0.75KW
• PU Foaming Finish Foil Paper Feeding Support: paper cutted by electric heating wire;
• Control system:control speed,tempearture,hydraulic&pneumatic operation and foaming flow;
• Double belt conveyor system: with motor 7.5KW;
• Double belt conveyor heating system: 24 groups of fluorescent lamp for heating(controlled by temperature controller);
• Air compressor: with 7.5kw motor,
• discharge air pressure: 0.7Mpa 7KG/CM2), 0.9M3/Min;
• Finished product Bandsaw Cutting System: no-stop cutting, gripping by pneumatic device,with 2.2KW cutting motor and 0.75KW feeding motor.

3.Finished Product Rack:two units,with wheel,un-powered

4. User's manual in English

Steel Tile PU Sandwich Panel Machine
(You can choose one profile drawing for your main machine)

Different steel tile PU sandich panel machine can make various thickness(15-100mm) of sandwich panel.These products have many advantages,such as resistance burning,keeping warm,sound insulation,easy installation.
The complete Steel Tile PU Sandwich Panel Machine line includes decoiler, main machine, computer controlling system and run out tables. Our machines are equipped with a computer controlling system. We simply program the pieces and length we need in the computer and the Steel Tile PU Sandwich Panel Machine machinery produces it automatically. The machines are easy to operate and running stable.

After-sale Service

1. The warranty of the machine is one year after the client receives the machine. Within the one year, we will courier the replacement parts to the client free of charge.
2. We offer technical support for the entire life of our machines.
3. We can send our technicians to install and train the workers in the clients' factories.

Terms of trade

1. Minimum order quantity (MOQ): 1 piece
2. Delivery time: 60 days
3. Port of loading: port of Xiamen
4. Type of payment: T/T
5. Export: Ireland, Poland,Romania, Czech,Mexico, India, Iran, Dubai, Iraq, Russia and others.

Machinery Shows

WE CAN MAKE PU SANDWICH PANEL / EPS SANDWICH PANEL, AND ALSO THE PU MACHINE AND THE EPS MACHINE. FOR MORE DETAILS, PLS CONTACT ME.
