Specifications
Brand Name :
Shenghong
Model Number :
SH-160712-3
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Supply Ability :
20 sets
Delivery Time :
60 days
Packaging Details :
Standard packing
Description

A.Detail Production Description

Highway Guardrail Roll Forming Machine, Manufacturer of Guardrail Roll Forming Machine

B.Technical Specifications of Highway Guardrail Roll Forming Machine, Manufacturer of Guardrail Roll Forming Machine

Type 311/508±5mm
Material thickness 3.0-4.0mm
Main motor power 37kw
Forming speed 5m/min
Hydraulic station power 11kw
Forming station 15 stands
Shaft Material and diameter Φ100mm, material is 45# steel
Length of guardrail As your requirement
Way of Drive Gear box
Control system PLC, Panasonic
Total Weight 15 tons
Voltage 380V/ 3phase/ 50 Hz
Size of the machine L*W*H 10 m*2.2m*1.7m
Material of Forming rollers Cr15
Cutting Blade: Cr12Mov

C.Main Components

Manual Decoiler x1 set

Hydraulic punching x1 set

Main roll forming machine x1 set

PLC Control System x1 set

Hydraulic cutting x1 set

Run-out table x1 set

D.Work Flow

Decoiler ---Feeding ---Leveling ---Punching---Roll forming --- Hydraulic cutting---Run-out table— Finish

E.Profile Drawing

Highway Guardrail Roll Forming Machine , Sheet Metal Roll Forming Machines

G.Our Advantage

Water proof,Fireproof,Anti-seismic
