Specifications
Brand Name :
Shenghong
Model Number :
Roof Tile SWL151218-64
Certification :
CE ISO
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
25 SETS/ MONTH
Delivery Time :
40 days after payment
Packaging Details :
1. Export standard package for container 2. Host nude, wheels with oil and gas bubble cushion packaging. 3. PLC controller with bubble cushion packaging 4. Spare parts in wooden cases.
Series :
Roller Shutter Door Roll Metal Forming Machine
Steel Sheet Thickness :
0.5-1.2mm or 1.5-2.5mm
Forming speed :
Approx. 3 - 15 m /min
Controls :
Panasonic Controls
Principal Axis :
45# high grade steel
Electric Elements :
PLC control panel, transducer imported from Mitsubishi of Japan
Description

Computer Controled Metal Forming Machinery For Roller Shutter Door

Specificatipn of Roller Shutter Door Rolling Forming Machine with

  1. Steel Sheet Thickness: 0.5-1.2mm or 1.5-2.5mm (depend on requirement )
  2. Covered Width: 82.3mm ( depend on prfoile )
  3. Coil Width: 134mm ( depend on prfoile )
  4. Decoiler: Manual Decoiler
  5. Capacity of Decoiler: 3 Ton
  6. Forming Speed: 5-15m/min
  7. Roller Groups: 13 stes main roller
  8. Roller Material: CCr15 high grade steel with finish machining treatment, by high frequency quenched HRC58-62
  9. Roller Diameter: 120mm
  10. Principal Axis: 45# high grade steel

PLC Control System

  1. Control the quantity & cutting length automatically;
  2. Combined with: PLC, Touch Screen (SIEMENS), Inverter (SCHNEIDER), Encoder (Omron), etc
  3. Cut-to-length tolerance≤±2 mm
  4. Control Voltage 24V
  5. Product Rack , Un-powered, 3 units

Machine Composition

  • 5Ton * 1250mm Hydraulic un-coiler
  • Hydraulic system expand coil inner hole, Pump motor
  • Frequency Inverter to regulate turning speed, Motor
  • Link-connect expanding system
  • Automatic stopping device, Load capacity
  • Coil Inner-diameter= 510±30mm, Coil width = Max.1250mm
  • Dance arm assistance for coil-turning speed control
  • Manual Pre-shearing device (Un-powered)
  • Smart cut control, to cut off the end of the final piece of sheet onl

Machine Shows

Computer Controled Metal Forming Machinery For Roller Shutter DoorComputer Controled Metal Forming Machinery For Roller Shutter Door
