Specifications
Brand Name :
Dingbo
Model Number :
DBSL
Certification :
CE ISO SGS
Place of Origin :
Jiangsu, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
30sets per month
Delivery Time :
within 45 days after receiving the deposit
Packaging Details :
Export package
Use :
sheet slitting
Material :
Stainless steel
Processing Thickness :
0.5mm-3mm
Processing Width :
500mm-1600mm
Slitting Speed :
0-100m/min
Max weight :
0-25T
Description

(0.3-3) X1600mm Automatic High Speed Slitting Line

Product Descriptions

The Metal slitting line achieves high productivity and high throughput by continuously shortening the setting time and high production speed.
The finest burr cutting process, the cutting edge is clean. High winding accuracy when rewinding the strip to the edge-aligned coil. Carefully handle to protect the strip surface. Perfect leveling effect on plates and strips. Low maintenance costs. Personalized, customized complete solutions for your finishing line.

The flow of the process

Coil car -- Decoiler -- Strightener -- Crop shear -- Looper -- Slitter -- Looper -- Recoiler --Coil car

Automatic High Speed Coil Slitting Line Crop Shear 3mm Stainless Steel Thickness

Product Parameters

Items Main specification
Material PPGI, GI, Aluminum, Carbon steel, Hot Rolled, Cold Rolled, Stainless steel
Thickness 0.5-3mm
Width 500-1600mm
Inner diameter 508mm, 610mm
Max outer diameter 1600mm
Max weight 10-25T
Slitting speed 0-100m/min
Max slit quantity 8 pcs (3mm) 25 pcs(0.5mm)
Power 380V/50Hz/3PH(Customized)
Whole line Dimension 24m(L)X8m(W)
Operator needed 1 mechanical engineer ,2 common workers
Line direction From right to left (Face to machine)


Main Components

No Name Quantity
1 Entry coil car 1 unit
2 Hydraulic Decoiler 1 unit
3 Hydraulic Press and pinch device 1 unit
4 Hydraulic cutter 1 unit
5 Looper 1 1 unit
6 Side guide device 1 unit
7 Slitter 1 unit
8 Scrap winder 1 unit
9 Looper 2 1 unit
10 Tension stand 1 unit
11 Recoielr 1 unit
12 Exit coil car 1 unit
13 Hydraulic system 1 set
14 Electrical system 1 set


Material picture

Automatic High Speed Coil Slitting Line Crop Shear 3mm Stainless Steel Thickness

Automatic High Speed Coil Slitting Line Crop Shear 3mm Stainless Steel Thickness

Automatic High Speed Coil Slitting Line Crop Shear 3mm Stainless Steel Thickness
