Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter
Specifications
Brand Name :
Shelok
Model Number :
SLK-MH-GR
Place of Origin :
Shaanxi, China (Mainland)
MOQ :
1piece
Price :
USD+160~200+Piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100+pieces+per month
Delivery Time :
5-8 work days
Packaging Details :
Standard export carton packing or can customized
Blind zone :
<0.25-1.5m
Range :
2m-30m (optional)
Accuracy :
±0.3%F.S
output :
4 ~ 20mA load impedance
Power supply :
DC12-32V
Description

Description of ultrasonic water fuel tank digital level meter:

MH-GR cast aluminum two-wire ultrasonic material (liquid) position meter is a two-wire ultrasonic measurement product developed by our company by taking advantage of many similar products at home and abroad. Using the latest energy-saving components, the whole working current is less than 3.5mA, and it can work reliably in the 9-32V DC power supply voltage. It is made of cast aluminum casing and comes with LCD display for convenient on-site setting. It can meet most of the level measurement requirements without touching the industrial medium, thus completely solving the shortcomings such as winding, clogging, leakage, medium corrosion and maintenance inconvenience caused by traditional measurement methods such as pressure type, capacitance type and float type. Therefore, it can be widely used in various fields related to material level and liquid level measurement and control. The upgraded version incorporates HART protocol communication support, which makes up for the shortcomings of the two-wire meter without data output, and can directly communicate with HART field instruments.

Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter

Specification of ultrasonic water fuel level meter
Range
2-30m(optional)
Blind area
<0.25- 1.5m
Minimum display resolution
1mm
Frequency
20 KHz ~ 43.0KHz
Accuracy
±0.3%F.S
Communication
HART Protocol
Incoming cable
user-defined length (internal terminal block)
Display
3 digit button operation, LCD display
Output signal
4 ~ 20mA load impedance (0 ~ 1KΩ) (standard)
Power consumption
<0.8W
Shell material
Cast aluminum
Interface
M20X1.5 (two wires)
Sensor
ABS, nylon
Working voltage
DC24-32V
Live setting
completed by local button
Emission angle
less than 12°
Ingress protection
IP65( (can be customized with higher protection level)
Explosion-proof grade
EXiaII BT4Gb
Working environment
normal temperature pressure
Storage humidity
≤80%RH without condensation

Application of Trade assurance three-wire ultrasonic level meters:

☆Water and sewage treatment Pump house, collection well, biochemical reaction tank, sedimentation tank, etc.
☆Electricity, mine mortar pool, coal slurry tank, butter storage tank, stockyard or part of mobile equipment control, etc.
☆Food Industry Winery, granary, food materials, tanks, etc.
☆ Control system supporting use

Ultrasonic 2m-30m ±0.3%F.S water fuel tank digital level meter

79mm × 210mm × G1 1/2 (2m range)
79mm × 223mm × M60 (5m-15m range)
79mm × 270mm × DN80 non-standard flange (20m-30m range)

Installation method:
G1 1/2 or ¢47mm round hole with large cymbal ring (2m range)
M60×2 or ¢61mm round hole with large ring (5m-15m range)
DN80 non-standard flange (20m-30m range)
