Grating | 1200 lines /mm |
Photocell | imported silicon photodiode |
Interface | USB& B.T |
WIFI module | standard |
Wireless printing | wireless B.T printer optional |
PC software | Optional |
Iot module software | standard |
plate holder | manual 1cm |
Display | 7-inch high resolution 1024*768 touch screen |
Monochromator | Holographic blazed grating C-T monochromator, proportional double beam |
Luminosity range | 0一200%T,0.3-3A |
Wavelength mode | Automatic |
Wavelength accuracy | ±0.3nm |
Wavelength repeatability | ±0.1m |
Spectral bandwidth | 2nm |
Wavelength range | 190-1100mm |
Stray light | 0.05T% |
Luminosity accuracy | ±0.5%T,±0.004Abs(00.5A):±0.008Abs(0.51A) |
Luminosity stability | ±0.15%T,±0.002Abs(00.5A):±0.004Abs(0.51A) |
Luminosity repeatability | ±0.5%T,±0.004bs(00.5A):±0.008bs(0.51A) |
Automatic lamp switching mode | Automatic ,340mm(optical) |
Stability | 0.001A(500nm,3min) |
Noise | 0.15T% |
