2、While ensuring the beauty, it greatly improves the practicality
3、Adjustable range | Accurate liquid extraction | Complete specifications
4、High strength、good toughness、fast rebound、not easy to deform
capacity | Adjustment amplitude | Check point | Capacity error | repeatability | Applicable suction head |
0.1-2.5μL | 0.05μL | 2.5μL1.25μL 0.25μL | ±3.0±6.0 ±12.0 | ≤ [3.0]≤ [4.0] ≤ [6.0] | 10μL |
0.5-10μL | 0.1μL | 10μL5μL IμL | ±3.0±6.0 ±10.0 | ≤ [2.0]≤ [3.0] ≤ [3.0] | 10μL |
2-20μL | 0.5μL | 20μL10μL 2μL | ±3.0±3.0 ±10.0 | ≤ [1.5]≤ [2.0] ≤ [3.0] | 20μL |
5-50μL | 0.5μL | 50μL25μL 5uL | ±24±2.8 ±6.0 | ≤ [1.5]≤ [2.0] ≤ [3.0] | 50μL |
10-100μL | 1μL | 100μL50μL 10μL | ±1.5±2.2 ±3.0 | ≤ [1.0]≤ [1.5] ≤ [2.0] | 100μL |
20-200μL | 1μL | 200μL100μL 20uL | ±1.5 ±1.5 ±3.0 | ≤ [1.0]≤ [1.0] ≤ [1.5] | 200μL |
100-1000μL | 5μL | 1000μL500μL 100μL | ±1.2 ±1.5 ±1.5 | ≤ [0.5]≤ [0.5] ≤ [1.0] | 1000μL |
