welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
Specifications
Brand Name :
OTC
Model Number :
FD-B4S
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
99
Delivery Time :
60days
Packaging Details :
welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot packing with fumigation wooden frame,
Number of Axes :
7
Maximum Payload Capacity :
4kg
Positional Repeatability :
+/- 0.08 mm (Note 1)
Horizontal Reach :
1435mm
Vertical Reach :
2446mm
Drive Capacity :
3550W
Description

welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot

Specification Value
Number of Axes 7
Maximum Payload Capacity 4 kg
Positional Repeatability +/- 0.08 mm (Note 1)
Horizontal Reach 1435mm
Vertical Reach 2446mm
Drive Capacity 3550W
Working Range, Arm, J1 (Rotation) +/- 170º
Working Range, Arm, J2 (Lower Arm) -145º~+70º
Working Range, Arm, J3 (Upper Arm) -170°~ +142.6°
Working Range, Wrist, J4 (Swing) +/- 155°
Working Range, Wrist, J5 (Bending) -45°~ +225°(Note 2)
Working Range, Wrist, J6 (Twist) +/- 205° (Note 2)
Maximum Velocity, Arm, J1 (Rotation) 3.66 rad/s {210°/s}
Maximum Velocity, Arm, J2 (Lower Arm) 3.66 rad/s {210°/s}
Maximum Velocity, Arm, J3 (Upper Arm) 3.66 rad/s {210°/s}
Maximum Velocity, Wrist, J4 (Swing) 7.33 rad/s {420°/s}
Maximum Velocity, Wrist, J5 (Bending) 7.33 rad/s {420°/s}
Maximum Velocity, Wrist, J6 (Twist) 10.5 rad/s {600°/s}
Wrist Load, Allowable Moment, J4 (Swing) 10.1 N*m
Wrist Load, Allowable Moment, J5 (Bending) 10.1 N*m
Wrist Load, Allowable Moment, J6 (Twist) 2.94 N*m
Wrist Load, Allowable Moment of Inertia, J4 (Swing) 0.38 kg*m@2
Wrist Load, Allowable Moment of Inertia, J5 (Bending) 0.38 kg *m^2
Wrist Load, Allowable Moment of Inertia, J6 (Twist) 0.03 kg *m^2
Arm operation cross-sectional area 2.57 m^2 x 340°
Environmental Conditions 0 ~ 45°C, 20 ~ 80 %RH (No condensation)
Mass 189 kg
Upper arm payload capacity 10 kg (Note 3)
Installation type Floor type
Paint color White (Munsell 10GY9/1)

welding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robotwelding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robotwelding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robotwelding robot OTC FD-B4S 7 axis of robot arm welding playload 4kg and reach 1.4m as mig welding robot
