Heating / Ventilation / Air Pneumatic Control Valve , Steel 3 Way Pneumatic Valve
Heating / Ventilation / Air Pneumatic Control Valve , Steel 3 Way Pneumatic Valve
Specifications
Brand Name :
Samson
Model Number :
3226
Certification :
CE EAC
Place of Origin :
Garmany
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, T/T, D/A, D/P, MoneyGram
Supply Ability :
500 Set Per Month
Delivery Time :
7 to 20 Workdays
Packaging Details :
Export wooden boxes for foreign trade, IPPC sterilized wooden boxes and plywood boxes for export customs inspection-free. Size: 60*30*40 (cm)
Valve size :
DN 25 to 250 NPS 1 to 10
Material :
Steel
Nominal Pressure :
PN 10 to PN 40 CL 150 and 300
Weight, approx. :
1.8 kg
Temperature Range of Medium :
–100 to +400 °C –148 to +752 °F
Description

Type 3226 Three-way Valve Control valves for use in heating, ventilation and air

Product Introduction

Valve Body Material  Cast carbon steel  Cast stainless steel  Low temperature carbon steel  Special alloys (Duplex, Hastelloy etc.)  Other special materials on request
Special features

Type 3226 Three-way Valve designed as a mixing valve with male thread connection and welding ends or threaded ends (DN 15 to 50) or with female thread connection (G ½ to G 1) • Type 3226 Three-way Valve designed as a diverting valve with male thread connection and welding ends or threaded ends (DN 15 to 50) • Type 3226 Three-way Valve combined with Type 5857 and TROVIS 5757-7 (with special spring) • Force-locking connection between valve and actuator • Type 3226 Three-way Valve (mixing or diverting valve) in special version: DVGW-tested

Specifications

Nominal size DN 15 20 25 32 40 50
Thread size ½ ¾ 1
Nominal pressure 25
Permissible temperature range +5 (–15) to 150 1)
Max. operating pressure 40 bar /50 bar

Temperature range of medium

 Medium: –100 to +400 °C
Opening angle 75°
Body CC499K (CuSn5Zn5Pb2-C)
Plug CW617N (CuZn40Pb2zh) with EPDM
Packing O-rings made of EPDM
Threaded ends Red brass


Detailed Image

Heating / Ventilation / Air Pneumatic Control Valve , Steel 3 Way Pneumatic Valve

Packaging and Delivery

Export wooden boxes for foreign trade, IPPC sterilized wooden boxes and plywood boxes for export customs inspection-free. Size: 60*30*40 (cm)

The products will be shipped after receiving the deposit or full payment within 15 working days

Our Service

1. Swift delivery
For common parts, we can deliver the goods within 3 days

2. Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.

3. Quality Assurance

4. Technical Support
Including inspection, repair, and maintenance, we can give all kinds of technical support.

5. Quickly response
Our staffs will keep 24h online and answer your question very quickly.
