500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
500kg/H Spent Brewers Beer Yeast Dryer Machine Centrifugal Atomizer 380V
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Shinma
Certification :
ISO9001, ISO14001
Packaging Details :
as per customer's requirement
MOQ :
2 sets
Price :
$38,000.00/sets 2-3 sets
Type :
Spray Drying Equipment
Application :
Medicine Processing, Chemicals Processing, Plastics Processing, Food Processing
Condition :
New
Voltage :
380
Power :
192
Dimension(L*W*H) :
16x12x16
Key Selling Points :
Automatic
Warranty :
1 Year
Weight (KG) :
15000
Applicable Industries :
Manufacturing Plant, Food & Beverage Factory, Farms, Food & Beverage Shops
Showroom Location :
None
Marketing Type :
Other
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
PLC
Evaporation Capacity(kg/h) :
300
Heating Method :
Steam Heating
Material :
SUS304, SUS304L, SUS316, SUS316L, Other
After-sales Service Provided :
Engineers available to service machinery overseas, Online support, Video technical support, Free spare parts, Field installation, commissioning and training
Machine material :
all SUS304/316L
After Warranty Service :
Video technical support, Online support, Spare parts
Local Service Location :
None
Description

LPG-500 Beer Yeast Spray Dryer spray drying equipment

Equipment design condition
1, Liquid conditions
Liquid product name: beer yeast liquid
Initial moisture: ~85% (design as 80%)
Final Moisture: ≤5%

Water evaporation capacity 500kg/h

The liquid temperature: Ambient temperature
2, Processing conditions
Spray method: Centrifugal atomizer
Liquid and the hot air contacting method: Co-current
Heat source and heating: Electric heating
Inlet temperature: 180~200℃(design as 180℃)
Exhaust temperature: 90~100℃(design as 85℃)
Product Capture mode: Cyclone separator + wet scrubber

Product collect mode: Frozen dehumidification product collect

3, the design weather conditions ( Standard )
Atmospheric pressure 101.3KPa
Environment temperature: 10 ℃
Relative Humidity: 80%
4, Public Works
4.1, Power
Power supply: 380V, 3 phase, 50HZ
Power: Drive 96.5kw + electric heating 1125kw

+ air sweeper electric heating 18kw
4.2, Compressed air
Pressure: 0.6 MPa
Consumption: 1.5m3/min

4.3, Water

Pressure: Cleaning water gun

Consumption: 1000kg/h
4.3, equipment covers an area space L × W × H 16m × 12m × 16m

Technical data sheet

Water Evaporation

500kg/h (pure water)

Diameter/Height

5.6M/13.5M

Operation temp

In 180℃-200℃ / Out 90-100℃

Atomizer

LPG-500

Rolling speed 15500 rpm

Diameter 150mm

Electricity Power

Drive 80kw

Heat supply

About 5.81 x105 kcal/h

Hot water consumption

1000kg/time (for cleaning)

Electric consumption

770-880 kilowatt-hour

Drying type

Open circle system

Feeding type

Screw pump

Hot air way

Co current

Heat source

Electric

Dust system

Cyclone separator + wet scrubber

Atomizer way

Centrifugal atomizer
