Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Shinma
Certification :
ISO14001 ISO9001
Packaging Details :
As per customer's requirement
Supply Ability :
30 Set/Sets per Year
Price :
$10,000.00/sets 1-2 sets
Type :
Fluid Bed Drying Equipment
Application :
Medicine Processing, Chemicals Processing, Food Processing
Condition :
New
Voltage :
380V/220V
Power :
3-45kw
Dimension(L*W*H) :
according the model
Key Selling Points :
Automatic
Warranty :
1 Year
Weight (KG) :
1100
Applicable Industries :
Manufacturing Plant, Food & Beverage Factory, Farms, Food & Beverage Shops
Showroom Location :
None
Marketing Type :
Other
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine
Evaporation Capacity(kg/h) :
7-750
Heating Method :
Steam Heating
Material :
SUS304, SUS304L, SUS316, SUS316L, Other
final product rate :
≥99%
After-sales Service Provided :
Online support, Video technical support, Free spare parts, Field installation, commissioning and training
After Warranty Service :
Video technical support, Online support, Spare parts
Local Service Location :
None
Port :
Shanghai
Description
FG high efficiency vertical fluid bed dryer granulator for pharmaceutical drying equipment
FG high efficiency vertical fluid bed dryer granulator for pharmaceutical
The material powder particles are in an annular fluidized state in the raw material container (fluidized bed). After being preheated and mixed by the heated air after purification, the binder solution is sprayed into atomization, so that several particles are gathered into agglomerates containing the binder. Due to the continuous drying of the material by the hot air, the water in the agglomerates evaporates. The binder solidifies, and this process is repeated continuously to form ideal and uniform microporous spherical particles.
FEATURES AT A GLANCE
1,The structure of fluidization bed is round so as to avoid the dead angle 2,Inside the hopper there is a stirrer in order to avoid agglomeration of raw material and forming canal of flow 3,The granule is discharged through the method of turning over. In this way it is very convenient. The discharging system can be designed as required too 4,It is operated at the condition of negative pressure and seal. The air is filtered. Therefore it is simple in operation and convenient in clean. It is an ideal equipment that is in conformity with the requirements of GMP. 5,The drying speed is fast and the temperature is uniform. In general, the drying time is 15-45 minutes each batch.
Typical application:
1.Granulation in the refrigeration industry: tablet granules, granular granules, capsule granules.
2. Granulation in the food industry: cocoa, coffee, milk powder, granular juice, condiments, etc. 3.Granulation in other industries:pesticides, feed, fertilizers, pigments, dye chemicals, etc. Drying of powdery or granular wet materials. Coating: granule, pill protective layer, color preparation, film, enteric coating, etc..
PRODUCT SPECIFICATIONS
No
Item
Data(choose as model 60)
1
Material container capacity(L)
220
2
Production capacity(KG)
Min30
Max90
3
Air volume(m³/h)
3000
4
Power(KW)
11
5
Steam consumption(kg/h)
141
6
Weight of main machine(KG)
1100
7
Temperature
Room temperature to 120℃(adjustable)
8
Operating time (min)
Depends on materials property 45-90
9
Final product rate (％)
≥99
10
Noise (dB)
≤75
11
Overall dimension(L*W*H)m
1.85*1.4*3
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Other model technical parameters
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Sketch of Flow Chart
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Why Choose Us
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Customer Photos
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
Vertical SUS316 Fluid Bed Granulator Mixer Granulator For Pharmaceutical Drying Equipment
