A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick
A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick
A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick
A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick
A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick
A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick
A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick
A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick
Specifications
Brand Name :
Gnee
Model Number :
A387
Certification :
SGS
Place of Origin :
Tianjin
MOQ :
1 Ton/Tons
Price :
$680 / Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
800 Ton/Tons per Week
Packaging Details :
Properly packed for ocean freight exportation in containers 1. Bundle 2. Water-proof Draft Paper
Standard: :
ASTM, bs, DIN, GB, JIS
Grade: :
A387
Place of Origin: :
Tianjin, China
Brand Name: :
Gnee
Model Number: :
According to customer requirements
Type: :
Steel plate/sheet/coil, Steel Plate
Technique: :
Cold rolled/Hot rolled
Surface Treatment: :
Coated
Application: :
Mechanical equipment, industry, metallurgy
Special Use: :
carbon steel plate, High-strength steel plate
Width: :
According to requirements
Length: :
According to requirements
Tolerance: :
±1%, Thickness+/-0.01mm
Product Name: :
standard astm a387 mild carbon steel sheet
Description

A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick

SA387 Steel Plate, Grades 5, 9, 11, 12, 22. Chromium – Molybdenum Alloy Steel Plates for elevated temp + corrosion. For Use in Boilers and pressure vessels.
Product Name Boiler Steel Plate
Material A387/SA387
Standard ASTM/ASME
Shape Flat
Surface Smooth
Certifications ISO, BV, SGS
Package Standard Seaworthy Export Standard
Usage Boiler, Pressure Vessel in Oil, Gas Industry
Advantages Stable Specification and Accurate Dimension
Service 24 hours online
Product Keywords astm a387 grade 11 class 1 steel plates,astm a387 alloy steel plate,alloy steel a387 gr 911 sheet suppliers

A387 Gr.22 CL.1 Steel Chemical Composition

Grade The Element Max (%)
C Si Mn P S Cr Mo
A387 Gr.22 Cl.1 0.04-0.15 0.50 0.30-0.60 0.035 0.035 1.88-2.62 0.85-1.15

A387 steel plate: Mechanical property

Grade Class Tensile Strength Yield Strength Elongation in 2 inches
(Mpa) min. (MPa) min. (%) max.
ASTM A 387 Grade 5 Class 1 415-585 205 18
ASTM A 387 Grade 5 Class 2 515-690 310 18
ASTM A 387 Grade 9 Class 1 415-585 205 18
ASTM A 387 Grade 9 Class 2 515-690 310 18
ASTM A 387 Grade 11 Class 1 415-585 240 22
ASTM A 387 Grade 11 Class 2 485-620 310 22
ASTM A 387 Grade 12 Class 1 380-550 230 22
ASTM A 387 Grade 12 Class 2 450-585 275 22
ASTM A 387 Grade 22 Class 1 415-585 205 18
ASTM A 387 Grade 22 Class 2 515-690 310 18

A387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm ThickA387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm ThickA387 Gr.22 CL.1 Steel Plate A387 Pressure Vessel Plates A387 Hot Rolled Steel Sheet 10mm Thick

We Gnee are experts in the supplying of materials to meet the individual requirements of a project, regardless of size, scope or difficulty.

As a specialized supplier of highly qualified products such as Seamless/Welded Pipe and Tube, Plate and Equipment for industries such as Shipbuilding, Pressure Vessel, Heat Exchager. Our main products are Corten Steel, Wear Resistant Steel, Marine Steel, Boiler Quality Steel.

We mainly service for industry of Oil & Gas, Petrochemical, Power Generation, Onshore & Offshore and other industry and energy field over the world.

FAQ

Q: Are you a manufacturer or trading company?

A: We are a specialized manufacturer.

Q: How about the delivery terms?

A: 1. Payment: T/T, Western Union, Paypal, 30% deposit in advance and balance before delivery.

2. Min. Order Quantity: 100KG, or as required.

3. Transportation: By express (DHL,TNT,FedEx),air,sea,and train.

Q: How about discount?

A: Price is based on products and order quantity.

Q: Do you accept sample order?

A: Yes sure, please contact us for details.

Q: How about your after-sales service?

A: As a professional steel exporter, we offer promote technology support for all problems and questions.

Besides, we accept goods return or replace for quality problem.

Q: How does your company control the quality?

A: Quality first. In order to guarantee high quality for our products,

Modern always makes a serious inspection for all products and raw materials in strict procedure.
