Specifications
Brand Name :
Gnee
Model Number :
A537
Certification :
SGS
Place of Origin :
Tianjin
MOQ :
1 Ton/Tons
Price :
$680 / Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
800 Ton/Tons per Week
Packaging Details :
Properly packed for ocean freight exportation in containers 1. Bundle 2. Water-proof Draft Paper
Standard: :
ASTM, bs, DIN, GB, JIS
Grade: :
A537
Place of Origin: :
Tianjin, China
Brand Name: :
Gnee
Model Number: :
According to customer requirements
Type: :
Steel plate/sheet/coil, Steel Plate
Technique: :
Cold rolled/Hot rolled
Surface Treatment: :
Coated
Application: :
Mechanical equipment, industry, metallurgy
Special Use: :
carbon steel plate, High-strength steel plate
Width: :
According to requirements
Length: :
According to requirements
Tolerance: :
±1%, Thickness+/-0.01mm
Product Name: :
standard astm a573 mild carbon steel sheet
Description

ASTM A537 CL3 quenched tempered pressure vessel steel sheet carbon steel sheet

The material is a normalised steel which is heat treated and as a consequence displays greater yield and tensile strength than the more standard ASTM A516 grades. The steel is ideal for use in pressurised service both in boilers and pressure vessels and Gnee supplies A537 Class 1 plates to the world's leading fabricators who in turn serve the Oil, Gas and Petrochemical industry.

Chemical composition:

C Si Mn Ni P S Cr Mo V N Nb Ti Al Cu -
max 0.18 max 0.5 1.1 - 1.7 max 0.5 max 0.025 max 0.015 max 0.3 max 0.08 max 0.1 max 0.012 max 0.05 max 0.03 max 0.02 max 0.3 Nb+Ti+V < 0.12

Mechanicial Properties:

Nominal thickness (mm): to 60 60 - 100 100 - 150 150 - 250
Rm - Tensile strength (MPa) (+N) 490-630 470-610 460-600 450-590
Nominal thickness (mm): to 16 16 - 40 40 - 60 60 - 100 100 - 150 150 - 250
ReH - Minimum yield strength (MPa) (+N) 355 345 335 315 305 295
KV - Impact energy (J) transverse, (+N) -20°
27-30		 0°
35-40		 +20°
39-50
KV - Impact energy (J) longitud., (+N) -20°
40-45		 0°
47-65		 +20°
55-75
Nominal thickness (mm): to 60 60 - 250
A - Min. elongation at fracture (%) (+N) 22 21

Detail information:

Thickness 5mm-150mm
Width 1000mm-4500mm
Length 3000mm-18000mm
Width 1000mm to 4500mm
Delivery Conditions UT (Ultrasonic Inspection), AR (Hot Rolling), TMCP (Thermo Mechanical Control), N (Normalization), Q + T (Quenching and Quenching), Z-Direction Test (Z15, Z25, Z35) , HIC test, nondestructive testing, PWHT (simulated post-weld heat treatment), NACE0175, Furnace Normalizing, Vacuum Degassing or as per customer requirement.
Application Boiler Plate, Pressure Vessel Plate, Ship Plate.

A537 Class 2 Plates Astm A537 Class 2 Carbon Steel Plate Astm A537 Class 2 Pvq SteelA537 Class 2 Plates Astm A537 Class 2 Carbon Steel Plate Astm A537 Class 2 Pvq SteelA537 Class 2 Plates Astm A537 Class 2 Carbon Steel Plate Astm A537 Class 2 Pvq Steel

Our Advantages

Gnee have our own workshop, we can supply one stop service:

1. Blasting machine cleaning the steel surface,
2. Fiber machine cutting the plate as the CAD drawings,
3. Bending machine,
4.Drill machine drill the holes.

Packing

1.Packing :3 layers of packaging, kraft paper inside, water plastic film in the middle, the outermost GI steel plate tied with
steel belt or as required.
2.Shipping port: Tianjin/Shanghai/Qingdao
3.Shipment:
a. Length: ≤6m, loaded in 20GP Container.
b. Length: ≤12m, loaded in 40GP Container.
Remark: Size of 20GP Container (inside :5898*2352*2393mm)
Size of 40GP Container (inside:12032*2352*2393mm)
Size of 40HQ Container (inside:12032*2352*2698mm)
4.Delivery time: Within 7-15 days, depending on the situation
