P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates
P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates
P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates
P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates
P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates
P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates
P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates
P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates
Specifications
Brand Name :
Gnee
Model Number :
P265GH
Certification :
SGS
Place of Origin :
Tianjin
MOQ :
1 Ton/Tons
Price :
$680 / Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
800 Ton/Tons per Week
Packaging Details :
Properly packed for ocean freight exportation in containers 1. Bundle 2. Water-proof Draft Paper
Standard: :
ASTM, bs, DIN, GB, JIS
Grade: :
P265GH
Place of Origin: :
Tianjin, China
Brand Name: :
Gnee
Model Number: :
According to customer requirements
Type: :
Steel plate/sheet/coil, Steel Plate
Technique: :
Cold rolled/Hot rolled
Surface Treatment: :
Coated
Application: :
Mechanical equipment, industry, metallurgy
Special Use: :
carbon steel plate, High-strength steel plate
Width: :
According to requirements
Length: :
According to requirements
Tolerance: :
±1%, Thickness+/-0.01mm
Product Name: :
carbon steel sheet
Description

P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates

Grade P265GH is the Heat Resistant Pressure Vessel Steels defined in the EN 10028 system. It is a non-alloy steel. The material is designed for high temperature applications. Therefore it is mostly utilized in high temperature applications in the oil and gas sector, chemical processing industries and petrochemical sectors.

P265GH Chemical Composition Max (%)

Grade C Si Mn P S Al(min) N
P265GH 0.20 0.40 0.80-1.40 0.025 0.015 0.020 0.012
Cr Cu Mo Nb Ni Ti V
0.30 0.30 0.08 0.020 0.30 0.03 0.02

P265GH Mechanical Property

Grade Thickness Yield Tensilmie Elongation Impact Energy(KV J) min
P265GH mm Min Mpa Mpa Min % -20° 0° +20°
≤ 16 265 410-530 22 27 34 40
16> to ≤40 255 410-530 22 27 34 40
40> to ≤60 245 410-530 22 27 34 40
60> to ≤100 215 410-530 22 27 34 40
100> to ≤150 200 400-530 22 27 34 40
150> to ≤250 185 390-530 22 27 34

40
Ordinary carbon structural steel plate
Q235A,Q275A,Q295A,SS400,AS3678-250, A36,SM400A, St37-2,
SA283GrA, S235JR, S235j0, s235j2, s275 Jr, s275j0, s275j2,s275n, S275NL, etc
Low alloy high strength steel plate
Q345A,Q355B,Q390A,Q420A,S420N,S420N, LS420M,S460M,
S420ML/S460ML,AS3678-300,AS3678-350,S460N,S460NL,SM490B,SM490YB, A572Gr50,A572Gr65, St52-3,S355JR, A709Gr50,A633C/D,
A633E,SM520,SM570,S315, StE355,StE460,S355JR, S355JO,S355J2,S355J2W,S355K2,S355N,S355NL
Offshore structural steel plate
S355G2+N,S355G3+N,S355G5+M,S355G6+M,S355G7+M,S355G7+N,
S355G8+M,S355G8+N,S355G9+M,S355G9+N,S355G10+M,S355G10+N
Steel plates for boilers and pressure vessels
SA387Gr11,SA387Gr22,15MnNiR,12Cr1MoVR, A515Gr60,(S)A515Gr65,(S)A515G70,(S)A516Gr60,(S) A516gr65, (s) a516gr70, (s) a516gr415, (s),A516gr485, (with s-handle) ASME standard,without ASTM standard), spv355, spv450,19Mn6,15Mo3 16Mo3,A573Gr70,SA285GrC,SB41,SP235GH,HII/P265GH, P295GH,P275NH,P275NL1,P355GH,P355NH,P355NL1,SA662GrC, P460nh,,A537CL1, a537cl2 (quenched and tempered steel),etc
Steel plate for bridge
Q235qc,Q345qc,Q370qc,Q420qc,Q345qDNH,Q370qDNH,A709-50F-2,A709-50T-2

P265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel PlatesP265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel PlatesP265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel PlatesP265gh Steel Plate P265gh Hot Rolled Steel Sheet P265gh Hot Rolled Steel Plates

Boiler and pressure vessel steel plate: professional pressure vessel steel plate used for the manufacture of the main equipment and parts of pressure vessels. The vast majority of pressure vessels are made of welded steel plates. In the manufacturing process, the pressure vessel steel plate must be subjected to hot and cold processing and welding, so the pressure vessel steel plate is required to have good technological performance, as well as a certain strength and enough toughness, so that under normal working conditions under the external load without brittle failure.
