BS DIN Standards P460 NL1 Polished Steel Sheet For Metallurgy
BS DIN Standards P460 NL1 Polished Steel Sheet For Metallurgy
BS DIN Standards P460 NL1 Polished Steel Sheet For Metallurgy
BS DIN Standards P460 NL1 Polished Steel Sheet For Metallurgy
BS DIN Standards P460 NL1 Polished Steel Sheet For Metallurgy
BS DIN Standards P460 NL1 Polished Steel Sheet For Metallurgy
BS DIN Standards P460 NL1 Polished Steel Sheet For Metallurgy
BS DIN Standards P460 NL1 Polished Steel Sheet For Metallurgy
Specifications
Brand Name :
Gnee
Model Number :
P460 NL1
Certification :
SGS
Place of Origin :
Tianjin
MOQ :
1 Ton/Tons
Price :
$680 / Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
800 Ton/Tons per Week
Packaging Details :
Properly packed for ocean freight exportation in containers 1. Bundle 2. Water-proof Draft Paper
Standard: :
ASTM, bs, DIN, GB, JIS
Grade: :
P460 NL1
Place of Origin: :
Tianjin, China
Brand Name: :
Gnee
Model Number: :
According to customer requirements
Type: :
Steel plate/sheet/coil, Steel Plate
Technique: :
Cold rolled/Hot rolled
Surface Treatment: :
Coated
Application: :
Mechanical equipment, industry, metallurgy
Special Use: :
carbon steel plate, High-strength steel plate
Width: :
According to requirements
Length: :
According to requirements
Tolerance: :
±1%, Thickness+/-0.01mm
Product Name: :
carbon steel sheet
Description

P460 NL1 Steel Plate P460 NL1 Hot Rolled Steel Sheet P460 NL1 Hot Rolled Steel Plates

Grade : P460NL1,P460NL2
Thickness : 8mm-150mm
Width : 2000mm-4000mm
Length : 1000mm-12000mm
MOQ: 1 PC
Product type : Steel plate
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Payment Terms: L/C, T/T, etc
Stock : Available
MTC: Available
Delivery condition: Q+T or +N
MTC: Original

EN10028 steel grade supersedes the older BS and DIN standards. P460NL1 steel grade is one of grade in En10028-3, which is non alloy and alloy steels with specified elevated temperature properties. P460NL1 grades are used above all for manufacturing boilers, pressure vessels and pipes transporting hot liquids.

P460 NL1 steel plate is one of the mainly High Yield steel, Boiler steel plates P460NL1 tensile strength is at 570_720 Mpa for thickness belows 60mm,even maximum 730 Mpa is OK for the product thicknesses up to 16 millimeters.

P460NL1 Chemical Composition Max (%)

Grade C Si Mn P S Al(min) N
P460NL1 0.20 0.60 1.0-1.70 0.030 0.020 0.025
Cr Cu Mo Nb Ni Ti V
0.30 0.70 0.10 0.005 0.80 0.03 0.20

P460NL1 Mechanical Property

Grade Thickness Yield Tensilmie Elongation Impact Energy(KV J) min
P460NL1 mm Min Mpa Mpa Min % -20° 0° +20°
≤ 16 460 570-720 17 47 55 63
16> to ≤35 450 570-720 17 47 55 63
35> to ≤50 440 570-720 17 47 55 63
50> to ≤70 420 570-720 17 47 55 63
70> to ≤100 400 540-710 16 47 55 63
100> to ≤150 380 520-690 16 47 55

63

BS DIN Standards P460 NL1 Polished Steel Sheet For MetallurgyBS DIN Standards P460 NL1 Polished Steel Sheet For MetallurgyBS DIN Standards P460 NL1 Polished Steel Sheet For MetallurgyBS DIN Standards P460 NL1 Polished Steel Sheet For Metallurgy
Why Choose Us?
Our advantages:
1. More than 17years Professional steel export service. Have own production line.
2. Advanced CNC machine.
3. Low cost&Quick Delivery&High quality
4. Integrity, strength and quality of products recognized by the industry.
5. Most of our clients are international, the domestic well-known enterprises
6. Has a complete scientific quality management system.
7. Can meet any requirements for all kinds of sheet metal processing with advanced equipment.
FAQ
1.Are you factory or trading company?
We are a factory and trading company. We have our own production line of cutting process. We can produce and ship according to the order. 2.The price you post on the website is the exact price?
What we publish on our website is the price range of steel plate reform. If you need, we can have a detailed discussion.
3.What’s your payment terms? T/T or L/C.
4.Can you provide samples ? Is it free ?
Yes, we could provide the sample for free charge without freight.
5.What’s the delivery time?
It takes only one week to ship from stock, while customized products need to be negotiated according to the specific order requirements.
6.If you provide cutting and other service or not?
Of course we could provide cutting as required or according to the drawing. The surface treatment and the port of shipment are also according to the order.
