Specifications
Brand Name :
Gnee
Model Number :
A514
Certification :
SGS
Place of Origin :
Tianjin
MOQ :
1 Ton/Tons
Price :
$680 / Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
800 Ton/Tons per Week
Packaging Details :
Properly packed for ocean freight exportation in containers 1. Bundle 2. Water-proof Draft Paper
Standard: :
ASTM, bs, DIN, GB, JIS
Grade: :
A514
Place of Origin: :
Tianjin, China
Brand Name: :
Gnee
Model Number: :
According to customer requirements
Type: :
Steel plate/sheet/coil, Steel Plate
Technique: :
Cold rolled/Hot rolled
Surface Treatment: :
Coated
Application: :
Mechanical equipment, industry, metallurgy
Special Use: :
carbon steel plate, High-strength steel plate
Width: :
According to requirements
Length: :
According to requirements
Tolerance: :
±1%, Thickness+/-0.01mm
Product Name: :
A514 mild carbon steel sheet
Description

A514 Gr Q Steel Plate A514 Hot Rolled Steel Sheet High Strength High Tensile Astm A514 Steel Plate

ASTM A514 Grade B high strength weldable steel plate is one of the high yield strength quenched and tempered alloy plates suitable for welding under the American Standard ASTM A514 / A514M. It is also called A514 Gr.B high strength weldable steel plate, which is one of the eight common specifications of ASTM A514 steel standard.

Product Name
Hot Rolled Steel Plate
Thickness
1mm-100mm
Width
1010,1219,1250,1500,1800,2500mm,etc
Length
1000,2000,2440,2500,3000,5800,6000,or as your requirement.

A514 Grade B Chemical Composition Max (%)

A514 Grade B C Mn P S Si Ni Cr Mo V Ti Zr Cu B Nb
0.12-0.21 0.70-10-.00 0.035 0.035 0.20-0.35 - 0.40-0.65 0.15-0.25 0.03-0.08 0.01-0.03 - - 0.001-0.005 -

A514 Grade B Mechanical Property

Grade Thickness Yield Tensile Elongation
A514 grade B mm Min Mpa Mpa Min %
20 690 760-895 18

A514 Gr B Steel Plate A514 Hot Rolled Steel Sheet High Strength High Tensile Astm A514 Steel PlateA514 Gr B Steel Plate A514 Hot Rolled Steel Sheet High Strength High Tensile Astm A514 Steel PlateA514 Gr B Steel Plate A514 Hot Rolled Steel Sheet High Strength High Tensile Astm A514 Steel Plate

We Gnee Mainly supply in forms of coil, sheet, plate, rod, bar, tube, pipe, beam, angle, flange, wire, strip, channel, etc., with various varieties, wide range of dimensions, high purity, stable chemical composition, high dimensional accuracy and excellent surface quality. The products are mainly used in the fields of industries such as automobile engineering, railway transportation, aviation, aerospace, machinery, petrochemical, energy, environmental protection, offshore, chemical, oil & gas, ilitary, power plant, nuclear power, pressure vessel, boiler equipment, mold manufacture, etc.
Our products:
• Pressure Vessel Steel
• Boiler Quality Steel
• HIC Resistant Steel
• Chrome Molybdenum Steel
• Composite Clad Plates
• Weathering Steels
• Structural Steels
• High Strength Steel Plate
• Heat Resistant Steel
• Bulletproof Steel Plate
• Wear Resistant Steel Plate

With high-quality products and brand advantage,our group has won the trust of clients and was approved by the partner all over the world.We are looking for coorperating with more and more friends worldwide for common development and benefits.
FAQ
Q: Are you trading company or manufacturer ?
A: We are professional manufacturer for many years. we can provide a wide range of steel products.
Q: Will you delivery the goods on time?
A: Yes,we promise to provide best quality products and delivery on time .Honesty is our company's tenet.
Q: Do you provide samples ? is it free or extra ?
A: The sample could can provide for customer with free,but the courier freight will be covered by customer account.
Q: Do you accept the third party inspection?
A: Yes absolutely we accept.
