Customized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm Thickness
Customized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm Thickness
Customized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm Thickness
Customized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm Thickness
Customized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm Thickness
Customized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm Thickness
Customized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm Thickness
Customized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm Thickness
Specifications
Brand Name :
Gnee
Model Number :
P690QL2
Certification :
SGS
Place of Origin :
Tianjin
MOQ :
1 Ton/Tons
Price :
$680 / Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
800 Ton/Tons per Week
Packaging Details :
Properly packed for ocean freight exportation in containers 1. Bundle 2. Water-proof Draft Paper
Standard: :
ASTM, bs, DIN, GB, JIS
Grade: :
P690QL2
Place of Origin: :
Tianjin, China
Brand Name: :
Gnee
Model Number: :
According to customer requirements
Type: :
Steel plate/sheet/coil, Steel Plate
Technique: :
Cold rolled/Hot rolled
Surface Treatment: :
Coated
Application: :
Mechanical equipment, industry, metallurgy
Special Use: :
carbon steel plate, High-strength steel plate
Width: :
According to requirements
Length: :
According to requirements
Tolerance: :
±1%, Thickness+/-0.01mm
Product Name: :
carbon steel sheet
Description

P690QL2 Steel Plate P690QL2 Hot Rolled Steel Sheet P690QL2 Carbon Steel Plates

Standard
GB, JIS, EN, ASTM
Material
P690QL2
Place of origin
Tianjin,China
Width
1000mm,1219mm,1250mm,1500mm,1800mm,2000mm,2200mm,2500mm,3000mm.ect.
Length
1000mm-12000mm or as required
Advantages
1.Short delivery time
2.Quality assurance
3.Competitive price
4.Superior Service

EN10028 P690QL2 STEEL PLATE EN10028-6 P690QL2 standard specification for Weldable fine grain steels, quenched and tempered.P690QL2 Mill Plate as well as the equivalent grades as per ASTM, ASME, JIS, EN, UNS Specs. We have about 3000tons of Pressure Vessel plates per each size in our port warehouses.

Grade : P690QL2
Number: 1.8888
Classification: Alloy special steel with low temperatupe properties down to -60 ? C
Standard:

EN 10028-6: 2009 Flat products made of steels for pressure purposes. Weldable fine grain steels, quenched and tempered

EN 10216-3: 2014 Seamless steel tubes for pressure purposes. Technical delivery conditions. Alloy fine grain steel tubes

P690QL2 Chemical Composition Max (%)

Grade C Si Mn P S N B
P690QL2 0.20 0.80 1.70 0.020 0.010 0.015 0.005
Mo Cu Nb Ni Ti V Cr
0.70 0.3 0.06 2.50 0.05 0.12 1.50

P690QL2 Mechanical Property

Grade Thickness Yield Tensile Elongation
P690QL2 mm Min Mpa Mpa Min %
6-50 690 770-940 14%
50-100 670 770-940 14%
100-150 630 720-900 14%

Customized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm ThicknessCustomized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm ThicknessCustomized Size Durable P690QL2 Pressure Vessel Steel Plate 20mm Thickness

Gnee is one of the biggest steel suppliers in China.Established in 2008, our factory is professional and trustworthy.We have built good and stable relationships with many customers in and abroad. Our products have been exported to many countries, such as Asia, India, Middle East, America, Europe,etc.
Our main products:hot rolled steel Plate,seamless steel pipe,carbon steel pipe,welded steel pipe,alloy steel pipe,stainless steel pipe,steel plate,steel pipe mill roll moulds and some other products. With a good reputation among domestic and overseas, we have many customers around the world.We are very glad to establish a long-term business relationship with you on the basis of mutual benefit. We believe that we will be your best partner in China.
FAQ

Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment.

If you need any help, pls feel free to contact me . And I will give you a good reply soonly. thanks for your attention in advance.
