Specifications
Brand Name :
GNEE
Model Number :
Nabla Elastic Rail Clips
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 Tons
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10000 tons per month
Delivery Time :
30 days
Packaging Details :
Gunny bags or cartons and wooden pallet
Type :
Nabla Elastic Rail Clips
Brand :
GNEE rail
Material :
60Si2MnA, 60Si2CrA
Size :
4mm or 4.5mm thick
Note :
42-47HRC 3 million times without breaking; Application for different rail type
Description

Nabla Elastic Rail Clips

The NABLA rail clip is specifically designed to support the NABLA fastening system, which is a popular choice for tram tracks throughout Europe. It is suitable for use on both ballasted and concrete sleeper tracks, delivering excellent performance on tight-radius curves. The clip ensures superior electrical insulation, effective lateral force absorption, and exceptional durability, thanks to its glass fiber-reinforced gauge blocks. GNEE Rail manufactures a comprehensive range of rail fasteners, including rail clips, joints, screws, anchor bolts, clamp plates, fishplates, and fishplate bolts, meeting global standards such as GB/TB, AREA, UIC, BS, DIN, ASTM, and AS. Contact us for further details.

Comprehensive Range of NABLA Elastic Rail Clips Manufactured by GNEE Rail

Nabla Clips Fastening system specification

Nabla clip Insulator Screw spike Spring washer
Pieces required 2 2 2 2
Material 60Si2MnA, 60Si2CrA Reinforced Nylon 66 (PA66) Grade5.6:35# ML08AI
Size 4mm or 4.5mm thick UIC54,UIC60,50kg rail,60kg rail 18.25x34x78mm
Note 42-47HRC 3 million times without breaking; Application for different rail type Density:1.3-1.45g/cm3 Tensile strength:≥170Mpa Elongation:≤4.4% Bending Strength:≥250Mpa Impact Strength(No gap):≥80KJ/m2 Melting point:250-270℃ Insultion resistance:≥1X108Ω Glass fiber content:30-35% Hardness:≥110HRR Tensile strength:≥500Mpa Yield strength:≥300Mpa Elongation:≥20% Cold bending:90 degree without crack Chemical composition(%): C:0.05-0.10, Mn:0.30-0.60, Si:≤0.1, Cr:≤0.2, P:≤0.035, S:≤0.035

Rail Nabla Clip technical parameters

Series Model Spec. Hardness
E rail clip III type rail clip ø18 44-48HRC
E1609 rail clip ø16
E1809 rail clip ø20
E1804 rail clip ø18
E1806 rail clip ø18
E1813 rail clip ø18
E2001 rail clip ø20
E2007 rail clip ø20
E2009 rail clip ø20
E2039 rail clip ø20
E2055 rail clip ø20
E2056 rail clip ø20
E2063 Rail Clip ø20
E2091 Rail Clip ø20
PR rail clip PR85 Rail Clip ø13
PR309A Rail Clip ø19
PR401 Rail Clip ø20
PR415 Rail Clip ø20
PR601A Rail Clip ø22
Vossloh clip& Forged rail clip SKL 1 Rail Clip ø13 42-47HRC
SKL 3 Rail Clip ø13
SKL 12 Rail Clip ø13
SKL 14 Rail Clip ø14
Special rail clip Special rail clip ø13
Russia rail clip Russia rail clip ø18
Deenik clip Deenik clip ø25
Anti-vandal clip Anti-vandal clip ø18
Fast clip Fast clip ø15
GL1419 GL1419 ø14
Nabla Spring blade Nabla Spring blade
KPO/rail clamp KPO/rail clamp
RAIL CLIP GANTREX RAIL CLIP GANTREX
We can also produce customized rail clips according to your drawings or samples.

GNEE rail clip workshop
