Specifications
Brand Name :
GNEE
Model Number :
D Type Rail Clip
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 Tons
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10000 tons per month
Delivery Time :
30 days
Packaging Details :
Gunny bags or cartons and wooden pallet
Material :
60Si2MnA
Color :
Customized
Hardness :
44-48 HRC
Standard :
Arema, BS, ASTM, UIC, TB
Surface :
Plain with anti-rust oil, Bluing (Black Oxide), Painting, Zinc Plating, HDG or as per requirement.
Description

D Type Rail Clip

Rail clips, also known as elastic rail clips, railway track clips, railroad rail clips, rail e-clips, or railway sleeper clips, are used to securely fasten rails to the underlying base (such as concrete sleepers or wooden ties) in railway track systems. D Type Rail Clip is characterized by its D-shaped configuration, which provides a secure and stable connection between the rail and the sleeper or baseplate. This design helps to maintain proper rail alignment and prevent shifting.

We are a premier manufacturer of railway fasteners, specializing in the development, production, and distribution of high-quality railway components. Our range of products includes D-shaped clips, E-shaped clips, SKL clips, fast clips, and other related accessories.

Our modern facility features a fully automated production line for rail clips, providing comprehensive services such as cutting, heating, forming, and heat treatment. We are committed to ensuring exceptional product quality and excellent customer service. For any inquiries or requirements, please feel free to contact us.

D Type Rail Clip Specification

Model: D Type Rail Clip

Brand: GNEE rail

Type: Elastic Railroad Clip, Railway Fastener clip, Railway Clip

Material: 60Si2Cr, 60si2Mn,38Si7 or according to customer needs

Hardness: HRC44-48

Toe load≥10KN

Application: Rail Clip Fastening System

D Type Rail Clip Technical Parameters

Item Materials Diameter Weight HRC Under pressure Fatigue test
Type III 60Si2MnA ø18 0.80kg 44-48 ≥950kgf 5000000
times
without
breaking
1809 60Si2MnA ø18 0.63 kg 44-48 ≥950kgf
e1609 60Si2MnA ø16 0.43 kg 44-48 ≥950kgf
e1813 60Si2MnA ø18 0.60 kg 44-48 ≥950kgf
e2001 60Si2MnA ø20 0.80 kg 44-48 ≥950kgf
e2007 60Si2MnA ø20 0.80 kg 44-48 ≥950kgf
e2009 60Si2MnA ø20 0.80 kg 44-48 ≥950kgf
e2055 60Si2MnA ø20 0.80 kg 44-48 ≥950kgf
e2056 60Si2MnA ø20 0.80 kg 44-48 ≥950kgf
e2063 60Si2MnA ø20 0.80 kg 44-48 ≥950kgf
PR401 60Si2MnA ø20 0.97 kg 44-48 ≥950kgf
PR415 60Si2MnA ø20 0.95 kg 44-48 ≥950kgf
PR601A 60Si2MnA ø22 1.23 kg 44-48 ≥950kgf
