3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
Specifications
Place of Origin :
China
Brand Name :
Zhongyuan
Certification :
CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc.
Model Number :
Standard and Customized
MOQ :
1
Price :
As per quotation
Packaging Details :
Pallet or Customized
Delivery Time :
As per offer
Payment Terms :
TT, L/C, Etc.
Supply Ability :
Satisfy clients needs
Model :
3Tx5m electric slewing crane
Lifting capacity :
3T
Working radius :
5m
Lifting speed :
6m/min
Rotation speed :
0.8r/min
Lifting motor power :
11kw
Rotary motor power :
2.2kw
Protection level :
IP56
Insulation class :
Class F
Control power supply :
24V safety voltage
Power :
AC380V. 3 phases. 50HZ
Working Temperature :
-40 to 50℃ Etc.
Surface treatment :
sandblasting to S2.5 + 3 layers of epoxy paint
Classification Certificates :
CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA
Description

3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment


Description:
3Tx5m electric slewing crane: mainly used for ships and marine engineering to lift fuel, fuel, chemicals, garbage, food, spare parts and other items. The column is a seamless steel pipe for marine use. The lifting mechanism is composed of a marine lifting motor with brake and a gear box, and a slewing mechanism is composed of a slewing bearing and a reducer. The lifting arm adopts steel square box girder, and the electric control box is controlled by far and short range!

Main Technical Specifications:

  1. Model: 3Tx5m electric slewing crane
  2. Lifting capacity: 3T
  3. Working radius: 5m
  4. Lifting speed: 6m/min
  5. Rotation speed: 0.8r/min
  6. Lifting motor power: 11kw
  7. Rotary motor power: 2.2kw
  8. Protection level: IP56
  9. Insulation class: Class F
  10. Control power supply: 24V safety voltage
  11. Power AC380V. 3 phases. 50HZ
  12. Working Temperature:-40 to 50℃ Etc.
  13. Surface treatment: sandblasting to S2.5 + 3 layers of epoxy paint,
  14. Classification Certificates:CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA.


Main Technical Parameters:

SWL
(Ton)

Working

Radius
(m)

 Slewing
Speed
(rpm)

Hoisting

Speed
(m/min)

Motor

Power
(kw)

 Pedestal Dia.
(Φ mm)
　0.5 2-8 0.8 12 　2.2/1.1 　450
　0.8 2-10 0.7 12 　2.2/1.5 　530
　0.9 2-10 0.7 12 　3.7/1.5 　630
　1 2-10 0.7 12 　3.7/1.5 　680
　2 2-15 0.7 12 　5.5/2.2 　800
　3 2-15 0.6 12 　7.5/3.7 　900
　4 2-15 0.5 12 　11/3.7 　900
　5 2-15 0.5 12 　15/5.5 　1100

3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment

Drawing of 3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment

3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment

3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment

3T 5m Electric Fixed Boom Slewing Crane With Tower Ship Deck Equipment
