32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
Specifications
Brand Name :
guanxiong
Model Number :
XY-DR320
Certification :
CE
Place of Origin :
jiangsu, China
MOQ :
1 pieces
Price :
$29900-16000/sets 1-99 sets
Payment Terms :
L/C, T/T
Supply Ability :
500 Set/Sets per Month
Delivery Time :
3-15 work days
Packaging Details :
Single package size:117X47X23 cm, weight:20kg
Power Source :
Electric
Warranty :
1 Year
After-sale Service :
Online technical support
Material :
Acrylic, Metal
Shelf Life :
1years
Nominal Electric Power :
20kw(100kv,320mA,100ms)
Instrument classification :
Class I
kKV range :
40-125KV
Max output power :
32KW
mA range :
10-400mA
Nominal focal spot value :
Large focus 1.2,Small focus 0.6
mAs range :
0.1~500mAs
Function :
Medical Diagnosis
Frequency :
≥30kHz
Description

Hot selling animal radiology equipment veterinary xray system x-ray machine dr

Power voltage 1-phase 220VAC ±10%,50Hz,16A；3-phase 380VAC±10%
Maximum Working Frequency ≥30KHz
Nominal Electric Power 20kw(@100kv,200mA,100ms)
KV range 40-125KV
mA range 10-320mA
mAs range 0.1-400mAs
Photoformy time 3ms-6300ms

X ray machine parameter:
Working voltage:40KV-125KV Maximum power (0.1 S): Small focus 20 kw, Large focus 40 kW Nominal value :Large focus 1.2,Small focus 0.6 Maximum heating filament characteristics :5.3A Anode speed (50HZ) :2800rpm Anode angle :12° Inherent filtering: 1.0mmAL/75kV Anode Heat Content: 110KJ(150KHU) Tube component heat capacity: 900KJ(1300KHU)

32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine

Flat panel detector parameter:
Flat Panel Detectors Detector Technology : a-Si Scintillator: CsI Image Size: 35×43 cm Pixel Matrix: 2560×3072 (14×17 in) Pixel Pitch: 140 μm A/D Conversion: 16 bit Minimum Detectable Dose: 14 nGy Maximum Linear Dose (RQA5): 110 μGy Spatial Resolution: 3.6 LP/mm Data Interface: GigE /802.11ac Power Dissipation: 20 W Adapter Input: AC 100-240V,50-60Hz Dimensions: 38×46×1.5 cm weight:3.3kgwireles/2.9kg wired
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
Analogue x ray machine accessories:
1. x ray machine with tube and table 1pcs
2. generator 1pcs
Wired DR x ray machine accessries:
1. x ray machine with tube and table 1pcs
2. generator 1pcs
3. wired flat panel detector 1pcs
4. software 1pcs
5. laptop 1pcs
32KW Digital Vet DR X-ray Table Small Animal Xray Fluoroscopy Equipment Fixed Veterinary Dog X Ray Machine
