Fully automatic 4 Color 4 Station Screen Printing Machine/ Diy insole T-shirt Press Printer With Related Machines

Fulund has a long history since its establishment in 1999. Due to the needs of development, the original brand (TYL) expanded the new brand Fulund in 2022 . Fulund has customers all over the world,such as international brands shoe manufacturer.
Fulund mainly products: Hot label machine, foam cutting machine, insole hot stamping machine, shoe tongue transfer hot stamping machine, insole heat transfer machine, insole cutting and transfer integrated machine, insole printing machine, silk screen printing machine, embossing machine, soft rubber equipment , vacuum vulcanizing machine, silicone labeling machine, glue dispensing machine, etc.

Features of automatic treadmill screen printing machine:
1. Compared with manual platen printing, the entire printing process of positioning, scraping, oil return, and shifting of the walking screen printing machine is fully automatic without manual intervention, which greatly reduces the labor intensity of the printing workers.
2. The pressure of the squeegee remains the same, the squeegee printing is stable, the oil return is uniform, and the printing color difference is small, which transfers the high dependence of the printing quality on the printing master.
3. The screen printing machine scratches once every 3 seconds, and runs continuously for 800-1200 times per hour, which greatly improves the production efficiency.
4. Optional side-wing dry air drying box can replace the ceiling fan to blow air in the workshop, and concentrate hot air while printing and drying, which can save energy and reduce consumption and reduce production costs while ensuring printing quality.
5. It can be combined with the customer's existing platen to make full use of existing resources and reduce the cost of technology upgrades.
6. The printing format from 600mmX800mm to 1800mmX1800mm can be customized to meet the needs of different printing formats.
7. Mechanical repeatability +0.1mm, overprinting accuracy +0.1mm, which can meet fine dot printing
8. It is designed with a fast plate-checking device, a fast and simple plate-changing device. After one plate-checking, there is no need to repeat the plate-checking, and the production efficiency will not be reduced due to plate-changing.
9. Using touch screen man-machine interface, a variety of humanized working modes, specially designed for multiple times of priming times setting program, priming can be set arbitrarily from 0 to 9 times, the priming process is automatically completed, and the operation is simple and easy to understand.
10. The three automatic platen screen printing machines only need one printing master operator, which greatly reduces the labor cost and solves the major trouble of the current enterprise recruitment difficulty.
11. The treadmill screen printing machine is generally used for a single-phase power supply with a power of 220V and 1kw, which is convenient for energy saving and suitable for more users.

Scope of application:
