0 ~ 500mg / Kg AC220V;50Hz Programmable constant temperature and humidity machine(GW-051C)
0 ~ 500mg / Kg AC220V;50Hz Programmable constant temperature and humidity machine(GW-051C)
0 ~ 500mg / Kg AC220V;50Hz Programmable constant temperature and humidity machine(GW-051C)
0 ~ 500mg / Kg AC220V;50Hz Programmable constant temperature and humidity machine(GW-051C)
0 ~ 500mg / Kg AC220V;50Hz Programmable constant temperature and humidity machine(GW-051C)
0 ~ 500mg / Kg AC220V;50Hz Programmable constant temperature and humidity machine(GW-051C)
Specifications
Brand Name :
Great Win
Model Number :
GW-051C
Certification :
CE CNAS
Place of Origin :
China
MOQ :
1piece
Price :
USD3000-6618
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 Pieces/Year
Delivery Time :
20 work days
Packaging Details :
Wooden case
Packaging :
Wooden Case
Power Supply :
AC220V;50Hz
Power :
about 3.5Kw
Measurement Range :
0 ~ 500mg / Kg
Dimensions :
Width 1010 X Depth 870 X Height 1760mm
Studio size :
Width 500 X epth 400 X Height 500mm
Description
0 ~ 500mg / Kg AC220V;50Hz Programmable constant temperature and humidity machine(GW-051C)
Product introduction:
The constant temperature and humidity test chamber is used to test electronic products, raw materials, toys, furniture, textiles, etc. under high and low temperature or hot and humid environments.
Main technical indicators of testing machine:
Studio size width 500 × depth 400 × height 500mm
Dimensions Width 1010 × Depth 870 × Height 1760mm
Temperature range -20 ºC ~ + 150 ºC
Temperature fluctuation ≤ ± 0.5 ºC
Temperature uniformity ≤ ± 2.0 ºC
Temperature deviation ≤ ± 2 ºC
Temperature rise and fall from + 20 ~ -20 ºC, about 60min, from + 20-100 ºC, about 40min
Humidity range 20%-98% R.H (AT + 25 ºC ~ + 85 ºC)
Humidity error + 2 / -3% R.H (above 75% R.H), ± 5% R.H (below 75% R.H)
Wind speed 1.7 ~ 2.5m / s;The above indexes are measured and tested in the environment within 1/6 space from the inner wall of the cabinet under the conditions of ambient temperature ≤25 ºC, normal pressure, no load and no load
Power about 3.5Kw
Power supply 220V ± 10% V; 50Hz

Meet relevant standards and test methods:
GB / T2423.22-87Nb,
GJB1032-90,
MIL-STD-2164 / (E / C),
GB / T2423.4- 93,
GB / T2423.34-86,
GJB150.9-86

0 ~ 500mg / Kg AC220V;50Hz Programmable constant temperature and humidity machine(GW-051C)
