Fixed Hydrogen Sulfide Gas Meter Continuous Operation 3000 Alarm Records
Fixed Hydrogen Sulfide Gas Meter Continuous Operation 3000 Alarm Records
Fixed Hydrogen Sulfide Gas Meter Continuous Operation 3000 Alarm Records
Fixed Hydrogen Sulfide Gas Meter Continuous Operation 3000 Alarm Records
Specifications
Brand Name :
Great Win
Certification :
CE CNAS
Place of Origin :
CHINA
MOQ :
1set
Price :
USD200-3500/Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 sets/year
Delivery Time :
10 work days
Packaging Details :
Carton case
H2S measurement range :
0-100ppm/0-1000ppm
Work pattern :
continuous operation, high and low alarm point
Response time :
<15S
Analog interface :
4-20mA signal output【option】
Storage :
3000 alarm records
Power consumption :
<10W
Operating temperature :
-40°C to +50°C
Working humidity :
15%-90% RH
Description

Fixed Hydrogen Sulfide Gas Meter

Brief Introduction:

Explosion-proof hydrogen sulfide sensors are specially developed for certain demanding environments. Cast aluminum explosion-proof housing, the probe is placed in a special metal probe chamber, and the electrical part is isolated from the probe.

Technical Specifications:

  • Sensor: catalytic combustion
  • Responding time: ≤40s(conventional type)
  • Work pattern: continuous operation, high and low alarm point(could be set)
  • Analog interface: 4-20mA signal output【option】
  • Digital interface: RS485-bus interface 【option】
  • Display mode: Graphic LCD
  • Alarming mode: Audible alarm -- above 90dB

Light alarm -- High intensity strobes

  • Output control: relay output with two way alarming control
  • Additional function: time display,calendar display
  • Storage: 3000 alarm records
  • Working power supply: AC95~265V, 50/60Hz
  • Power consumption: <10W
  • Water and dusk proof: IP65
  • Temperature range:－20℃ ～ 50℃
  • Humidity range:10 ～ 90％(RH)No condensation
  • Installing mode: wall-mounted installing
  • Outline dimension: 335mm×203mm×94mm
  • Weight: 3800g

III,Technical parameters of gas-detecting

Table 1: Technical parameters of gas-detecting

Measured Gas Gas Name Technical standards
Measuring Range Resolution Alarming point
H2S hydrogen sulfide 0-100PPM 1PPM 10PPM

IV,Acronyms

ALA1 Low alarm

ALA2 High alarm

Prev Previous

Set Para Parameter settings

Com Set Communication settings

Num Number

Cal Calibration

Addr Address

Ver Version

Min Minutes

V,Product configuration

1,Wall-mounted detecting alarm one

2,4-20mA output module (option)

3,RS485 output (option)

4,Certificate one

5,Manual one

6,Installing component one
