SMD1515 Indoor Fixed Ultra Thin LED Display Front Maintenance LLED Screen IP31
SMD1515 Indoor Fixed Ultra Thin LED Display Front Maintenance LLED Screen IP31
SMD1515 Indoor Fixed Ultra Thin LED Display Front Maintenance LLED Screen IP31
SMD1515 Indoor Fixed Ultra Thin LED Display Front Maintenance LLED Screen IP31
SMD1515 Indoor Fixed Ultra Thin LED Display Front Maintenance LLED Screen IP31
SMD1515 Indoor Fixed Ultra Thin LED Display Front Maintenance LLED Screen IP31
Specifications
Brand Name :
Showtechled
Model Number :
HD Series-P2.0
Certification :
CE/FCC/ETL/EMC
Place of Origin :
China
MOQ :
1SQM
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10000sqm/month
Delivery Time :
15-25 work days
Packaging Details :
cartons cases/wooden cases/flight case
Model Name :
HD2.0
Pixel Pitch :
P2.0mm
Brightness (cd/㎡) :
1000cd/㎡
Pixel density :
250000dots/㎡
LED configuration :
SMD1515
Cabinet resolution :
320(W)*240(H)
Cabinet weight :
6KG
Cabinet size :
640(W)*480(H)*50(D)mm
Description


HD Series -- Showtechled Indoor Fixed Full Color LED Display Front Maintenance Wall Ultra Thin LED Screen

(1) Description of Indoor Fixed Front Maintenance Wall Ultra Thin LED Display:

1. Full Front Service:LED modules, receiver cards and power supplies can be maintained in the front.

2. Perfect display ratio: 4:3 ratio, so that videos and pictures get a perfect display effect.

3. Light and Thin: Die casting Magnesium alloy cabinets only 6kg and 50mm thickness.

4. High Contrast:Black SMD LED and high gray scale makes perfect performance.

(2) Quick Detail:

Product Pitch: 2mm

Module Size: 320mm*160mm

Cabinet Size: 640mm*480mm

Refresh rate: 3840Hz.

IP Rating(Front/Rear): IP31

Life Span: 100,000Hours

(3) Specifications:

Module Detail
1ItemHD2.0
2Pixel Pitch2.0mm
3Pixel density250000dots/㎡
4LED configurationSMD1515
5Module size320(W)×160(H)×12(D)mm
6Module resolution160(W)x80(H)
7Module weight0.5Kg
8Scanning Mode1/40
9IC modelFM6353
Cabinet Detail
1Cabinet resolution320(W)x240(H)
2Cabinet size640(W)×480(H)×50(D)mm
3Cabinet materialDie casting Magnesium alloy
4Cabinet weight6kg
5Module number2*3
6Brightness1000cd/㎡
7Viewing angle160°(horz.), 160° (vert.)
8Optimal View Distance2m-20m
9Gray scale14(bit)
10Max Power Consumption450W/㎡
11Avg Power Consumption150W/㎡
12Work VoltageAC190-264V
13Frame Frequency60Hz
14Refresh rate3840Hz
15Operation SystemWin7&XP
16Control ModeSynchronization with PC
17Operating Temp.( -40℃～+ 50℃ )
18IP Rating(Front/Rear)IP31
19maintenance typeFront maintenance
20Life Span100,000Hours

Notes:

1. Open the package, check the product slowly, and handle it with care to avert damage to the product.

2. Regularly check whether the power and signal lines are broken or bitten.

3. The power supply should be stable, and the grounding protection should be good. Regularly check the reliability of the lightning conductor and grounding system.

4. Regularly inspect whether the anti-corrosions and anti-rust paint on the surface of the product and steel structure welding points is peeling off. If there is peeling or rust, spray anti-rust paint or apply anti-rust paste in time.

Application:

Widely used suitable for buildings, factory, conference rooms, monitoring rooms, stadiums, airports, shopping malls, restaurants, hospitals and other places.

SMD1515 Indoor Fixed Ultra Thin LED Display Front Maintenance LLED Screen IP31


FAQ:

Q1. Can I have a sample order for led display?

A1: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. Do you have any MOQ limit for led display order?

A2: Low MOQ, 1pc for sample checking is available.

Q3. What is your shipping and packing way?

A: Our standard packing for modules are carton box and for the led cabinet, we do wood box or flight case as per customers’ requests. For the mass order ( fit for a container), generally we do shipment by Sea.

Q4. Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.
