Specifications
Brand Name :
HYF
Model Number :
HYF
Certification :
ISO, SGS, etc.
Place of Origin :
China
MOQ :
1000KG
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, PayPal
Supply Ability :
3000Ton/Month
Delivery Time :
15-20 work days
Packaging Details :
Standard Export Package
Material :
PETG, PET
Thickness :
30mic-70mic
Width :
200-1200mm
Feature :
High clarity
Shrinkage :
Shrink up to 75%
Use :
Eco-Friendly Shrink Sleeve
Description

40 - 50 μ Eco-Friendly Printable Heat Shrinkable PETG Film Roll For Sleeve


1. Product Description

Our shrinkable film is a polyester film that adheres to an assortment of packaging. It is typically used for labeling of containers made from materials such as PET, PS, PE, glass, and cans. Some of the characteristics are:

Optically Excellent – The clarity of this film enables eye catching graphics when printed.


Great Processibility – This film has a uniform thickness and is dimensionally stable. It is a high performance film that works very well in the printing, slitting, sealing and labeling processes. Post processing, this film maintains its profile which results in an outstanding finished product.
Superb Stability at Room Temperature – These films will not shrink when stored, or transported at room temperature thus saving on special transport, or cooling bills.


High Temperature Resistant – At high processing temperatures, the stable characteristics of this film are evident. Whether used as a label, or cap seal the end product is one that can be depended on to meet, or exceed expectations of quality.

2. Specification


1) Thickness: 30-70μ


2) Width: 450-1200mm


3) shrinkage:high and medium shrinkage


4) Standard export pallet packing


5) Applications:electrical insulation

3. Technical Data Sheet

Pet Shrinkable film for shrink sleeve thickness


Pet Shrinkable film for shrink sleeve tensile strength


Pet Shrinkable film for shrink sleeve modulus of elasticity


Pet Shrinkable film for shrink sleeve coefficient of friction


Pet Shrinkable film for shrink sleeve surface wetting tension


Pet Shrinkable film for shrink sleeve heat shrinkage

No Test Item UNIT Standard Test Result Decide
1 (Average thickness deviation) μm ±3 0 Qualified
2 TENSILE STRENGTH (MD) MPa ≥42 65.8 Qualified
(TD) MPa ≥142 231
3 ELONGATION (MD) % ≥300 591 Qualified
(TD) % ≥35 55
4 Elasticity Modulus (MD) MPa ≥1500 3269 Qualified
(TD) MPa ≥3000 7370
5 Heat Shrinkage (MD) % ≤5.0 2.3 Qualified
(TD) % 70~80 78
6 Haze % ≤7.0 2.2 Qualified
7 C.O.F (IN/OUT) dynamic friction coefficient / ≤0.50 0.47 Qualified
8 Wetting Strength mN/m ≥38 ≥38 Qualified
9 Density g/cm3 1.32±0.3 1.46 Qualified

PVC-HYF286.pdf

3. Technical Characteristics

1) Good transparency and brightness.

2) High level of thermal shrinkage.

3) Special for high performance lines.

4) Suitable for any environment and climate.

5) Resistant to UV rays, special to protect the stored product and the weather or in its transport.

4. Application

1) Full- or partial-body shrink sleeves


2) Full- or partial-body roll sleeves


3) Multi-packs


4) Tamper-evident bands


5) Wine capsules and disk plates


6) Pressure-sensitive shrink labels

Printable Heat Shrinkable PETG Film Rolls For Sleeve , 40 - 50 μ Eco Friendly

6. FAQ

1) Q: Do you accept OEM?
A: Yes, we do.


2) Q: What's your delivery time?
A: It’s according to the quantity of the order. Normally it is between 5 and 20 days.


3) Q: What's your production capacity?
A: About 4000 tons per month.


4) Q: What's your payment term?
A: We accept T/T, L/C, O/A, Western Union, or customized if it is acceptable.


5) Q: Do you provide free sample? And how many days it will take?
A: Samples for testing are available and free. The freight for sample delivery is at receivers's side. But to be refunded by deducting from the right coming order automatically
