2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover
Specifications
Brand Name :
CHC
Model Number :
T5Pro and X6
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1000 per year
Packaging Details :
With Standard Packing Way
Description

2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover

2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover

2022 Year China Hot Sales Professional Rtk Receiver Chc Ibase with Imu Chc X6/T5PRO Rover

Project

 Content Parameter
Receiver characteristics satellite tracking GPS+BDS+Glonass+galileo+QZSS, supporting the third generation of Beidou, achieving 5 stars and 16 frequencies
number of channels 624 channels
operating system Linux system
Initialization time
Initialization reliability >99.99%
Receiver appearance button 1 dynamic/static switch key, 1 power key
Indicator light 1 differential signal light, 1 satellite light
Display screen 1 LCD display
Nominal accuracy Static accuracy Plane accuracy: ±(2.5+ 0.5×10-6×D) mm
Elevation accuracy: ±(5+0.5×10-6×D) mm
RTK accuracy Plane accuracy: ±(8 + 1×10-6×D) mm
Elevation accuracy: ±(15+ 1×10-6×D) mm
Single machine accuracy 1.5m
Code difference accuracy Plane accuracy: ±(0.25+ 1×10-6×D) m
Elevation accuracy: ±(0.5+ 1×10-6×D) m
Electrification parameters Battery Removable 14000mAh lithium battery, support base station 12+ hours battery life
External power supply The host can be powered by DC power supply, 220V AC power supply, and can directly power the host through the radio (9-24) V DC
Physical properties size Φ160.54 mm*103 mm
weight 1.73kg
Material Magnesium alloy AZ91D body
Operating temperature -45℃~+85℃
storage temperature -55℃~+85℃
humidity 100% non-condensing
Waterproof and dustproof IP68 level
Shock vibration IK08 level
Anti-drop Resistance to free fall of 2 meters
Data communication I/O interface 1 external UHF antenna interface
1 seven-pin data port interface, support power supply, differential data output
1 nano sim card slot
Built-in esim, free of charge for surveying and mapping for three years at the factory
Radio station Built-in transceiver, power: up to 5W
Network module Support 4G full Netcom
Wi-Fi 802.11 b/g/n
Blue tooth BT 4.0, backward compatible with BT2.x, protocol support Win/Android/IOS system
NFC Support NFC flash connection
Data output Output format NMEA 0183, binary code
output method BT/Wi-Fi/RS232/Serial
Static storage storage format Direct recording of HCN, HRC, RINEX, compressed RINEX
storage Standard 8GB storage, support space protection
Download method FTP remote push + local one-click download, HTTP download
Receiver Super twin Support radio + network two-way data differential at the same time, provide comprehensive data services
one-button start ChinaTest researches and develops data link concurrent communication technology, and the base station is set up immediately
