OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
Specifications
Brand Name :
SIBO
Model Number :
Q896S
Certification :
CE, FCC
Place of Origin :
Shenzhen
MOQ :
2 units
Payment Terms :
T/T
Delivery Time :
5-25 working days
Packaging Details :
10 pcs in one carton
OS :
Android 6.0
CPU :
Allwinner A83T 8-core
screen :
multiple capacitive touch screen
RAM :
2GB
ROM :
8GB
network :
wifi, 3G, Ethernet,blurtooth
power supply :
DC IN or POE
interface :
camera, USB, HDMI output, RJ45,DC IN
serial ports :
RS232, RS485, GPIO
Optional accessories :
NFC, three-colors LED, temperature sensor, light sensor
Bracket :
Onwall, inwall, glass wall, table
Supply Ability :
2000pcs/month
Description
7 inch Wall Mount Android 6.0 POE Tablet
with wifi Ethernet Blutooth For Intelligent Home Loxone

Detailed Product Description

LED Color: Blue, Green, Red Power Supply: DC IN 9V-36V/Power Over Ethernet
Wall Mount: Inwall, Onwall, Glass Wall Mount Application: Loxone Smart House Controlling
PoE: Power Over Ethernet, IEEE802.3af Network: 3G/WIFI/Ethernet
System: Android 6.0 CPU: Allwinner A83T Octa-Core
Display: 7 Inch IPS Display Resolution: IPS 1024*600
Industrial Automation /Smart Home Control System 7 Inch IPS Screen Wall Mount Android Tablet 2GB RAM With POE

OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control

  • IPS Screen (G+G glass)
  • Three color led light on the top to show room status (blue, red, green)
  • Android OS
  • In wall / On wall version / Glass wall mount
  • HDMI, Serial port , GPIO , Uart interface
  • No buttons design
  • Slim Body with 3 Brackets for wall mounting
  • Camera & Mic
  • Support ROOT permissions for private application
  • No battery design
  • Auto power on
  • 12V DC / 24V DC available for power
  • Auto web application (one web page can be showed only on the screen)
  • POE feature (IEEE 802.3 af)

Application :

  • Meeting romm Schedule,
  • Office control region,
  • Home Automation,
  • Industrial control

Customized Service:

  • Customized animation firmware with your logo (available in bulk order)
  • Temperature/Humidity Sensor
  • Customized USB jumper for app debugging

Standard accessories;

  • WIFI
  • Bluetooth
  • Camera
  • Power adapter

Optional accessories:

  • PoE
  • NFC RFID Reading module
  • LED indicating bar
  • Arduino Nano
  • RS232
  • RS485
  • GPIO

With multi color controllable Indicator on the top (red / green / blue), suitable for meeting room applications, home automation and control

Demo application software and source code will be provided for you to integrate LED control feature into your own software.

OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control

OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control

OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control

Specification:

Model Number Q896S
Hardware Specs Solution Allwinner’s A83T processor
CPU Octa-core Cortex tm-7a CPU A83T 1.2Ghz
Display 7 Inch IPS Display, Resolution:1024 x 600, Brightness: 350 cd/m2
RAM 2GB
Nand Flash 8GB
Software Feature System Google Android 6.0
Audio One Speaker 1 X 1 Watt (Integrated 3W Amplifier)
Language Support multi-languages
Interfaces Back Ethernet Interface(RJ45)
HDMI Out
USB 2.0 port USD HOST Mode Default, Optional: Jumper Cap for Device Mode
DC IN Power Terminal (9V-36V)
Optional:RS232,RS485,1xGPIO IN, 1xGPIO OUT
Network WIFI+BLUETOOTH WIFI (802.11b/g/n), Bluetooth 4.0 support BLE
LAN Port Ethernet RJ45
Power Supply DC IN or PoE DC 9V - 36V or PoE
Boot Up Auto Boot Auto Boot Up When Power Supplies

It is Wall Tablet / Desk Tablet, no battery , no buttons (with auto power on feature), it is a serial port Tablet , It is a GPIO tablet, all good features for home automation and so on...

A real POE tablet PC can works with POE standard of IEEE 8023.AF, compatible with 12V DC.

OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control

DC+ POE for power supply

OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control

OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control
Q896S INTERFACE:
1.HDMI OUT
2.CVBS IN(Removed)
3.DC IN (9-24V)
4.RJ45
5.USB
6.UART, IO , 3W AMP OUT
7.SLOTS FOR MOUNTING
8.SCREWS FOR MOUNTING
In wall installation :
OEM/ODM7 inch Wall Mount Android 6.0 POE Tablet , touch screen For Intelligent remote control

Welcome OEM orders !

Contact person

Miss Nancy,

Skype/Wechat: chinasibo

QQ: 153083978
