6500-7100MHz Frequency Controlled Oscillator Customized Specifications
6500-7100MHz Frequency Controlled Oscillator Customized Specifications
6500-7100MHz Frequency Controlled Oscillator Customized Specifications
6500-7100MHz Frequency Controlled Oscillator Customized Specifications
6500-7100MHz Frequency Controlled Oscillator Customized Specifications
6500-7100MHz Frequency Controlled Oscillator Customized Specifications
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
RFint
Model Number :
YSGM657103
Price :
Prices are negotiable
Packaging Details :
Opp bag
Delivery Time :
2-10days
Payment Terms :
T/T,Western Union,MoneyGram
Specification :
Standard
Packaging Type :
opp bag
Application :
6500-7100MHz
Package / Case :
Standard
Series :
VCO
Features :
Standard
Size / Dimension :
7mm*9mm*2mm
Description :
Standard voltage controlled oscillator
Output power :
≥3dBm
Supply voltage :
4V~6V
Working current :
10mA
Description
Innotion YSGM657103 Standard VCO 6500-7100MHz Voltage Controlled Oscillator for Customized Specifications
Product Description
6500-7100MHz Frequency Controlled Oscillator Customized Specifications

YSGM657103 is a highly integrated, standard package size VCO, using a high cut-off frequency RF transistor as an oscillating tube with high output power and good isolation.
This VCO uses high stability oscillation circuit structure, high precision varactor diode and high output power RF Triode to ensure stable starting waveform and high output power.
It adopts 5V standard voltage, which is compatible with the working voltage in the range of 4V and 6V, and has a wide tuning voltage range, which can realize the output of wide band and high power.

Characteristic parameter
Nominal tuning frequency band 6500-7100MHz@VT=0.5V~4.5V
Output power ≥3dBm @VCC=5V
In-band flatness (BW≤200MHz) ±1dB
Power supply voltage (VCC) 4V ~ 6V
Working current 10mA
Second harmonic suppression ≤ -20dBc
Third harmonic suppression ≤ -30dBc
Radio-frequency output impedance 50Ω
Universal package size 7mm x 9mm x 2mm

6500-7100MHz Frequency Controlled Oscillator Customized Specifications

6500-7100MHz Frequency Controlled Oscillator Customized Specifications

Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Zhongshi Zhihui Technology (suzhou) Co., Ltd. is located in Suzhou Industrial Park, founded in 2010, the company is mainly engaged in, and can provide customers with wireless communication network coverage solutions of high-tech enterprises. The company implements radio-oriented development strategy based on radio frequency technology, independent research and development and production of bidirectional frequency conversion super WiFi signal amplifier products, radio frequency and microwave voltage controlled oscillator (VCO), sweep signal source, wireless network card information security module and other product lines, has mastered some core technologies in the product field, has a lot of independent intellectual property rights.
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2010,sell to Western Europe(50.00%),Southern Europe(12.00%).

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

1 year warranty for our products.

3.what can you buy from us?

Signal Booster, VCO, Anti drone jammer module, Power Amplifier, Gain Block and so on
