80kva Trailer Type Water Cooled Diesel Generator With Soundproof Canopy
80kva Trailer Type Water Cooled Diesel Generator With Soundproof Canopy
80kva Trailer Type Water Cooled Diesel Generator With Soundproof Canopy
80kva Trailer Type Water Cooled Diesel Generator With Soundproof Canopy
80kva Trailer Type Water Cooled Diesel Generator With Soundproof Canopy
80kva Trailer Type Water Cooled Diesel Generator With Soundproof Canopy
Specifications
Brand Name :
Weichai Generator
Model Number :
SW80M5
Certification :
ISO 2000&9001
Place of Origin :
China
MOQ :
1 unit
Price :
5,000-6,000 USD/unit
Payment Terms :
L/C, T/T
Supply Ability :
90-96 units per month
Delivery Time :
one month
Packaging Details :
plastic film or wooden case
Prime power :
64kw/80kva
Type :
open/silent/weatherproof/trailer type
Frequency :
50/60 Hz
Application :
Telcom,shopping mall,hospital,building,railway,school,etc
Alternator :
Stamford/Leroy Somer/Marathon/Wattek
Voltage :
400/415/480/460/440/240/230/220 V
Standby Power :
70kw/88kva
Dimension :
2000*850*1250mm (open type)
Displacement :
4.1 L
Description

Water cooled diesel generator 80kva trailer type 50hz&60hz with soundproof canopy coupled with stamford alternator

Why to choose weichai diesel generator?As weichai is one of the biggest diesel engine manufacture in the world now,sold more than 1 million units diesel engines in 2021.Weichai has global after service network all over the world and enjoy global warranty.

Famous brand+Good quality+Global warranty+Competitive price,that is the advantage of Weichai generator.

Weichai website:www.weichai.com

Technical parameters:

Generator set Model No. SW80M5
Standby power 88KVA/70KW
Rated power 80KVA/64KW
Output voltage 230/400
Rated speed (r/min.) 1500
Noise level(7m) 72dB (silent type)
Power factor COSΦ=0.8(lagging)
Phase/wires 3 phase 4 wires
Start mode Electric
Fuel consumption 14.8L/h (Average)
Rated currency(amps) 115
Protection Low oil-pressure, High water temperature, Over-speed, Over-current.
Engine Brand Weichai
Model WP4.1D80E200
Original: China
Cylinders 4
Fuel 0# light diesel
Inter-Cooling N/A
Compression Ratio 17.5:1
Engine Power (prime/standby) 72KW/80KW
Aspiration NA
Governor/Class Mechanical
Bore and stroke 105×118 mm
Start mode DC24V electric start
Cylinders Layout In Line
Displacement 4.1 L
Alternator Brand Leroy Somer
Model TAL-A44-C
Protection IP23
Frequency fluctuation ≤±0.5 %
Voltage distortion ＜4%
Prime Power 88KVA(70KW)
Original China
Rated voltage 400/230 V
Frequency regulation ≤±0.5 %(stable)
Voltage control AVR

Technical parameters of Control Panel:
Brand Smartgen Model 6110 80kva Trailer Type Water Cooled Diesel Generator With Soundproof Canopy
Function:

• Start or Stop Generator set manually / automatically

• Open controller output can be defined as Pre-heat/Idle output

• High Coolant temperature protection

• Low Oil pressure protection

• Over load protection

• Generator over/under frequency protection

• Generator over/under/unbalance voltage Protection

• Over speed protection

• AMF
Note:Indicate this function depend on the set points of the controller in field.

Standard Accessories Open type Silent type
Sound-proof & Weather-proof Canopy N/A √
Daily base fuel tank. 8 hours capacity Option √
Single-bearing generator again drops √ √
Intelligent LED display control panel √ √
Speed governor √ √
Electric start and 12v charger √ √
Standard air filter, oil filter, fuel filter √ √
Cooling water tank √ √
High-efficient silencer. √ √
Circuit breaker √ √
Exhaust elbow √ √
Storage battery √ √
Steel base-frame against vibration √ √
Soft pipe for fuel and handle for lube going-out √ √
Operation& Maintenance manual. √ √

　Drawing Dimension
80kva Trailer Type Water Cooled Diesel Generator With Soundproof Canopy

Open type:

2000*850*1250mm
80kva Trailer Type Water Cooled Diesel Generator With Soundproof Canopy

Silent type:

2700*1250*1700 mm　

FAQ:

Q1:How about the warranty of weichai series diesel generator set?

Stone Power provides a full line of brand new and high quality products. Each Genset is strictly factory tested before delivery.

We offer client warranty of 12 months or 1,000 running hours warranty which comes first (longer warranty period can be offered with extra charge)

Weichai engine and Stamford/Marathon/Leroy Somer alternator also enjoy worldwise after service offered by their global after service network.

Quick after service and parts are available from Stone Power or distributors in your location.

Q2:If I want to visit your factory,how can I get?

Our factory Address: Guanshan industrial area. jingqiao town. lishui district. Nanjing .JIANGSU China.Welcome to visit our factory,our factory located in Nanjing City,China,about 1 hour by car from Nanjing Airport or South Nanjing railway station.We can pick you up at Nanjing Airport or railway station.
